Parts List - HOMCOM A91-180 Assembly & Instruction Manual

EN
No. Name
1 Main Tube
2L/2R
Leg Extension Upright L/R
3 Uprights
4 Upright Support Bar
5 Connect Tube
6 Backrest Adjustable Rod
7 Handle Bar
8 Plate bar
9 Front Support Tube
10 Front Adjust Tube
11 Front Stabilizer
12 Rear Stabilizer
13 Lock U
14 Pin
15 Backrest Pad
16 Knob M10

PARTS LIST

Qty No.
1 17
1 18
2 19
1 20
1 21
1 22
2 23
2 24
1 25
1 26
1 27
2 28
2 29
4 30
1 31
2
10
Name
Support Cushion
Hex Screw M10*60
Hex Screw M10*65
Hex Screw M10*50
Hex Screw M10*16
Nut M10
Cap Nut M8
Flat Washer Ø10
Arch Washer Ø8
Carriage BoltM8*60
Flat Washer Ø6
Screw M6*10
S13-14-15 Tool
Wrench
Hex Screw M10*70
Qty
2
2
4
3
6
6
2
24
2
2
6
6
1
1
2
