Parts List - HOMCOM A90-308 Assembly Instruction Manual

No. Description
1 Screw
2 Washer
3 Front Stabilizer
4L/R End Cap
5 Screw
6 Inertial Wheel
7 Mesh Belt Pulley
8 Handlebar
9 End Cap
10 Foam Grip
11 N/A
12 Nut
13 Wave Washer
14 Rear Support
15 End Cap
16 End Cap
17 Sliding Rail
18 Mesh Belt
19 Belt
20L/R Chain Cover L/R
21 Screw
Volute Spring
22
Cover
23 Outer PC Board
24 Volute Spring
Mesh Belt Wheel
25
Axle
26 PC Board
27 Bearing
28 C-Clip
29 Bearing
30 Belt Wheel

PARTS LIST

Spec. QTY.
M8*15*S6 6
d8*Φ16*1.5 20
1
2
ST4.2*20 11
1
1
Φ25*1.5*420 1
Φ25*15 2
Φ26*3*200 2
-
M10*1*H5 4
d10*Φ13.5*0.3 2
1
2
1
1
t1.5*22*2150 1
6PJ220 1
2
ST4.2*16 8
1
Φ111*Φ16*0.5 1
t0.5*22*5080 1
1
1
6300-2RS 1
d35 1
16003-2RS 2
Φ112*67.5 1
-17-
No. Description
31 Bearing
32 Belt Wheel
33 Bearing
34 Adjusting Screw
35 Bolt
36 Handlebar Seat
37 Screw
38 Mesh Belt Pulley
39 Screw
Left Seat
40
Supporting Board
41 Adjusting Screw
42 U Shape Baffle
43 Nut
44 N/A
Tension Control
45
Knob
46 Washer
Right Seat
47
Supporting Board
48 Computer
49 Main Frame
50 Grommet
51 Trunk Wire 1
52 C-Clip
53 Wheel
54 Bearing Steel
55 Bearing
56 Magnet
57L/R Pedal L/R
58 Nut
59 Bolt
60 Bolt
Spec. QTY.
Φ35*d17*16 1
1
6000-2RS 1
M6*40*Φ10*2.5 2
M8*125*20*S6 1
106*40*31 1
M8*15*S6 4
1
M5*15 3
1
M6*40*Φ9*2.5 2
30*10*1.5 4
M6*H6*S10 6
-
1
d5*Φ20*1.5 1
1
1
1
Φ12*11*Φ3 3
1
d6 2
3
1
608RS Φ8*Φ22*12 8
Φ15*7 1
L/R 320*140*55 2
M12*S19 2
12*M12*P1.75*460 1
Φ12*440 1
