SPARE PARTS LIST
NO.
DESCRIPTION
1
Main frame
2
Pedal support tube(L)
3
Pedal support tube(R)
4
Upper stand tube
5
Lower stand tube
6
Handle tube
7
Pedal
8
Bushingφ60
9
Pull pin
10
Monitor base
11
Monitor
12
Foam for handlebar
13
Bushing φ76
14
Adjusting knob
15
Hydraulic cylinder
16
Round cap
17
Shaft sleeve
18
Plastic plug □35
19
Rubber stopper
20
Magnet
21
Nut cap
22
Sensor
23
Clip
24
Bracket
25
Connecting rod
26
Connecting sheet
QTY.
NO.
1
27
Plastic washer
1
28
T-shaped steel washer
1
29
Plastic washer
1
30
Plastic plugφ25
1
31
Flat washerφ19
1
32
Circlip
2
33
Plastic washer
1
34
Hex screw M12x80
1
35
Flat washerφ12
1
36
Nut M12
1
37
Inner hexagon screw
M8x30
2
38
Flat washerφ8
1
39
Inner hexagon screw
M8x40
1
40
Hex screw M8x50
2
41
Cross screw ST5x10
2
42
Flat washerφ5
4
43
Inner hexagon screw
M8x20
2
44
Connecting line
2
45
Inner hexagon screw
M8x25
1
46
Plastic cover
1
47
Nut M8
1
48
Cross screw ST5x16
1
49
Arc-shaped washer
1
50
Front end cap
2
51
Rear end cap
1
16
DESCRIPTION
QTY.
1
1
1
2
4
2
12
1
2
1
4
20
4
4
1
1
4
1
2
1
12
4
4
2
2
