Note: This Output is used only in MULTIPACK or PYTHON units.
The output will come ON under three distinct conditions:
1. Pump Enabled (A), Engine Speed < 900 RPMs(B) and the chassis is in Neutral (C). (i.e. stationary operation.)
2. Pump Enabled (1A), Engine Speed < 900 RPMs(1B), chassis Service brake is applied (1C) and vehicle MPH is <7 (1D) (i.e. slowing
down and coming up to a stop.)
3. Pump Enabled (2A), Lift Stow (2B), Grabber Open button (2C), Grabber not fully opened (2D) OR Lift not fully stowed (2E) (i.e.
stowing lift while pulling away from a stop.)
D11 Transmission Temperature Indicator (Output %QX0.13)
This output function controls the Transmission indicator light.
Related Option Configurations
Option Status
Selected Truck Type 7000 OIGAI
Conditions Necessary to activate the circuit:
Condition Logic Function or Component
A - Lift Pump (P1)
B AND Trans Temp Switch
Note: This Output can be used only in 7000 O.I.G.A.I. unit. With condition A true, condition B will activate the Transmission
temperature indicator. The indicator will flash, once per second, when Fault #31 is set. This indicates the transmission fluid temperature
has exceeded a safe operating range.
D12 Throttle Limit (Output %QX0.13)
This output function controls the engine Throttle Limit circuit. Used on operate at idle DPF700 unit
Related Option Configurations
Option Status
Selected Truck Type 7000 OIN
Conditions Necessary to activate the circuit:
Condition Function or Component
- System Power Switch
A
AND Hydraulic Pump Enable PB
B AND Chassis Neutral
Note: This Output can be used only in 7000 O.I.N. unit. With (A) true, condition 'B' will activate the Engine Throttle Limit.
Section 5: Special Features
5.01: Select-O-Pack
Select-O-Pack is a standard feature on all CORTEX controlled Automated side loader products.
This feature automatically cycles the Auto-Pack after a predetermined number of lift cycles.
Copyright 2024, The Heil Co.
Printed in the U.S.A.
Body Controller Software
Functionality
Output %QX0.13 Is Used as Trans Temp Indicator
Status
Activated
Deactivated
Functionality
Output %QX0.10 Is Used as Grabber Closed
Status
Activated
Activated
AND
Activated
I/O Status
Address
%QX0.14 ON
%IX0.13 OFF
I/O Address Status
%IX0.15 ON
%IX0.04 ON (momentary)
%IX1.04 ON
