118
B03 LIFT LOWERED PROX (PYTHON UNIT)
B04 THROTTLE ADVANCE SWITCH (MULTIPACK UNIT)
B05 LIFT RAISED PROX (7000 O.I.G.A.I. AND O.I.N. UNITS)
B06 PACKER TRAVEL POSITION SWITCH
B07 TRASMISSION TEMPERATURE SWITCH
B08 IN-CAB ENABLE, REAR STROBE
B09 IN-CAB ENABLE, TURN SIGNAL
B10 OIL LEVEL SWITCH
B11 BODY DOWN PROX. (NON-MULTIPACK UNITS)
B12 TAILGATE BUZZER SWITCH (MULTIPACK UNIT)
STANDARD OUTPUTS
C01 REAR STROBE (IN-CAB ENABLE ACTIVATED)
C02 PACKER PUMP (P2)
C03 LIFT RETRACT SOLENOID (MULTIPACK AND PYTHON UNIT)
C04 PACKER RETRACT SOLENOID
C05 PACKER EXTEND SOLENOID
C06 LIFT RAISE SOLENOID (MULTIPACK AND PYTHON UNIT)
C07 FILTER BYPASS INDICATOR
C08 LIFT EXTENDED INDICATOR
C09 TAILGATE OPEN INDICATOR
C10 LIFT PUMP (P1)
C11 IN-CAB ALARM
MULTI-FUNCTION OUTPUTS
D01 BODY RAISED (PYTHON)
D02 THROTTLE ADVANCE (MULTIPACK UNIT)
D03 TAILGATE HYDRAULIC POWER (MULTIPACK UNIT)
D04 FRONT STROBE (IN-CAB ENABLE ACTIVATED) (NON-MULTIPACK UNITS)
D05 OUT OF DIMENSION WM
D06 GRABBER CLOSE SOLENOID
Issued July 2024
Body Controller Softw are
Body Controller Software
%IX0.06 P1-11
%IX0.06 P1-11
%IX0.06 P1-11
%IX0.13 P1-2
%IX0.13 P1-2
%IX1.07 P1-37
%IX1.07 P1-37
%IX1.07 P1-37
%IX2.01 P1-49
%IX2.01 P1-49
%QX0.00 P1-44
%QX0.02 P1-46
%QX0.03 P1-47
%QX0.04 P1-36
%QX0.05 P1-54
%QX0.07 P1-53
%QX0.08 P1-39
%QX0.09 P1-3
%QX0.12 P1-41
%QX0.14 P1-43
%QX0.15 P1-4
%QX0.01 P1-45
%QX0.01 P1-45
%QX0.06 P1-17
%QX0.06 P1-17
%QX0.06 P1-17
%QX0.10 P1-40
