INSIGHT™ STANDARD DIAGNOSTIC DISPLAY CABLE
See the figure below for a rear view of the display with cable connected.
CORTEX CONTROLLER™ PROGRAMMING
Contact Heil Environmental for re-programming of the Cortex Controller.
PROGRAMMING CABLES AND ADAPTERS
Issued July 2024
Body Controller Hardw are
Body Controller Hardware
Figure 53. Rear View of Display with Cable Connected
Description
Cortex Controller RS232 Cable
InSight™ CAN Programming Cable
USB to RS232 Adapter
USB to CAN Adapter
USB to M12 Cable (USB to 7" and
12" Displays)
Part Number
263-1678
263-1721
108-8619
108-8620
108-8714
Copyright 2024, The Heil Co.
Printed in the U.S.A.
