User Manual Modbus Slave / KNX
Document code: MN67813_ENG
Revision 1.003
Pagina 14 di 26
Industrial Electronic Devices
ETHERNET (PROGRAMMING PORT):
The Ethernet ports are used for programming the device.
The Ethernet connection must be made using Connector2 of HD67813-KNX-xxx-B2 with at least a Category 5E cable. The maximum length
of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To
connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC is recommended the use of a
cross cable.
ADFweb.com Srl – IT31010 – Mareno – Treviso
INFO:
www.adfweb.com
Phone +39.0438.30.91.31
