Industrial Electronic Devices
User Manual
Revision 1.000
English
IO-Link / Modbus TCP Slave - Converter
(Order Code: HD67863-A1-2A, HD67863-A1-4A,
HD67863-A1-2B, HD67863-A1-2A-2B)
for Website information:
www.adfweb.com/?Product=HD67863
for Price information:
www.adfweb.com/?Price=HD67863-A1-2A
www.adfweb.com/?Price=HD67863-A1-4A
www.adfweb.com/?Price=HD67863-A1-2B
www.adfweb.com/?Price=HD67863-A1-2A-2B
Benefits and Main Features:
Triple electrical isolation
Two Ethernet ports
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual IO-Link / Modbus TCP Slave
Document code: MN67863_ENG
Revision 1.000
For others IO-Link devices, see also the following links:
IO-Link from/to ...
www.adfweb.com?Product=HD67860
www.adfweb.com?Product=HD67861
www.adfweb.com?Product=HD67862
www.adfweb.com?Product=HD67864
www.adfweb.com?Product=HD67865
www.adfweb.com?Product=HD67866
www.adfweb.com?Product=HD67867
www.adfweb.com?Product=HD67868
www.adfweb.com?Product=HD67869
www.adfweb.com?Product=HD67870
www.adfweb.com?Product=HD67871
www.adfweb.com?Product=HD67872
www.adfweb.com?Product=HD67873
www.adfweb.com?Product=HD67874
www.adfweb.com?Product=HD67875
www.adfweb.com?Product=HD67876
www.adfweb.com?Product=HD67877
www.adfweb.com?Product=HD67878
Do you have an your customer protocol?
See the following links:
www.adfweb.com?Product=HD67876
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Page 1 of 36
(Modbus Master)
(Modbus Slave)
(Modbus TCP Master)
(BACnet Master)
(BACnet Slave)
(CAN)
(CANopen)
(DeviceNet Master)
(DeviceNet Slave)
(EtherNet/IP Master)
(EtherNet/IP Slave)
(J1939)
(MQTT)
(NMEA0183)
(NMEA2000)
(PROFINET Slave)
(SNMP Manager)
(SNMP Agent)
Phone +39.0438.30.91.31
Advertisement
Table of Contents
Related Manuals for ADF Web HD67863-A1-2A
Summary of Contents for ADF Web HD67863-A1-2A
- Page 1 Revision 1.000 Page 1 of 36 User Manual Revision 1.000 English IO-Link / Modbus TCP Slave - Converter (Order Code: HD67863-A1-2A, HD67863-A1-4A, HD67863-A1-2B, HD67863-A1-2A-2B) for Website information: www.adfweb.com/?Product=HD67863 For others IO-Link devices, see also the following links: for Price information: IO-Link from/to …...
-
Page 2: Table Of Contents
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 2 of 36 UPDATED DOCUMENTATION: INDEX: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated... -
Page 3: Security Alert
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 3 of 36 SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 4 of 36 EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 5: Connection Scheme
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 5 of 36 CONNECTION SCHEME: Figure 1a: Connection scheme for HD67863-A1-2A ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... - Page 6 User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 6 of 36 Figure 1b: Connection scheme for HD67863-A1-4A ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
- Page 7 User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 7 of 36 Figure 1c: Connection scheme for HD67863-A1-2B ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
- Page 8 User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 8 of 36 Figure 1d: Connection scheme for HD67863-A1-2A-2B ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
-
Page 9: Characteristics
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 9 of 36 CHARACTERISTICS: The HD67863-A1 is a IO-Link / Modbus TCP Slave converter. It allows the following characteristics: Up to 1500 bytes in reading and 1500 bytes in writing; Two-directional information between Modbus TCP and IO-Link;... -
Page 10: Power Supply
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 10 of 36 POWER SUPPLY: The devices can be powered between a wide range of tensions. For more details see the two tables below. Vmin Vmax HD67863-A1-xx... -
Page 11: Function Modes
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 11 of 36 FUNCTION MODES: The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’: The first, with Dip1 in Off position (factory setting), is used for the normal working of the device. The second, with Dip1 in On position, is used for upload the Project/Firmware. -
Page 12: Leds
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 12 of 36 LEDS: The device has got five LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state... -
Page 13: Io-Link
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 13 of 36 IO-LINK IO-Link is the first globally standardized IO technology (IEC 61131-9) that communicates from the controller down to the lowest automation level. -
Page 14: Aux Power Supply
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 14 of 36 IO-L LASS IO-Link Class B devices uses 5 pins on connectors and they require an additional aux power supply used for the actuation. These devices are normally actuators. -
Page 15: Ethernet
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 15 of 36 ETHERNET: The Ethernet connection must be made using Connector5 of HD67863-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. -
Page 16: Use Of Compositor Sw67863
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 16 of 36 USE OF COMPOSITOR SW67863: To configure the Converter, use the available software that runs with Windows called SW67863. It is downloadable on the site www.adfweb.com and its operation is described in this document. -
Page 17: New Project / Open Project
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 17 of 36 NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “IO-Link / Modbus TCP Slave - Converter”... -
Page 18: Software Options
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 18 of 36 SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. In the section “Language”... - Page 19 User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 19 of 36 In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 20: Set Communication
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 20 of 36 SET COMMUNICATION: This section defines the fundamental communication parameters of Modbus TCP. By Pressing the “Set Communication” button from the main window for SW67863 (Fig. 2) the window “Set Communication”... -
Page 21: Io-Link Set Access
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 21 of 36 IO-LINK SET ACCESS: By Pressing the “IO-Link Set Access” button from the main window for SW67863 (Fig. 2) the window “IO-Link Set Access” appears (Fig. 4). This section is used to define the list of IO-Link variables accessible from Modbus TCP side. - Page 22 User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 22 of 36 In the “List of IO-Link Channel” section it is possible to configure all the IO-Link channels of the converter (Fig. 5). Figure 5: “List of IO-Link Channel”...
- Page 23 User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 23 of 36 By clicking on “Insert IODD”, the window “IO-Link IODD Catalog” appears (Fig. 6). This section is used to select an IO-Link device. By clicking on “Add IODD”...
- Page 24 User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 24 of 36 The “Process Data” section is used to define the IO-Link process data to link to Modbus TCP side (Fig. 7). Figure 7: “Process Data” section The meanings of the fields are: In the field “Id”...
- Page 25 User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 25 of 36 The “Device Function – Variables” section is used to define the IO-Link parameters to link to Modbus TCP side (Fig. 8). The meanings of the fields are: In the field “Index”...
- Page 26 User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 26 of 36 In the field “TotBitLen” the bit length of the array to which the IO-Link parameter refers is defined; In the field “BitOff” the bit offset of the IO-Link parameter is defined; In the field “Default”...
- Page 27 User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 27 of 36 The “I/O Options” section is used to define how linking the data from IO-Link pin 2 and pin 4 to Modbus TCP side (Fig. 9). Figure 9: “I/O Options”...
- Page 28 User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 28 of 36 The “Events” section is used to define the IO-LINK events to map on Modbus TCP side (Fig. 10). Figure 10: “Events” section The meanings of the fields are: In the field “Code”...
- Page 29 User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 29 of 36 In “Device Identity” section (Fig.11) and “Transport Identity” section (Fig. 12), the main features of the selected IO-Link device are reported. These characteristics are read from the IODD file. Figure 11: “Transport Layers”...
-
Page 30: Update Device
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 30 of 36 UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. - Page 31 User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 31 of 36 Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67863 device. Warning: If Fig.
-
Page 32: Modbus Map
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 32 of 36 MODBUS MAP: Data in reading: Type Address Function Description Bytes 0-1 of internal array (Position) Input Register Bytes 2-3 of internal array (Position) Input Register Bytes 4-5 of internal array (Position) Input Register... -
Page 33: Mechanical Dimensions
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 33 of 36 MECHANICAL DIMENSIONS: Figure 15: Mechanical dimensions scheme for HD67863-A1-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 34: Ordering Informations
A: 1M, 35mm DIN Rail mounting Device Family HD67863: IO-Link / Modbus TCP Slave - Converter Order Code: HD67863-A1-2A IO-Link / Modbus TCP Slave – Converter (IO-Link ports: 2 x Class A) Order Code: HD67863-A1-4A IO-Link / Modbus TCP Slave – Converter (IO-Link ports: 4 x Class A) Order Code: HD67863-A1-2B IO-Link / Modbus TCP Slave –... -
Page 35: Disclaimer
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 35 of 36 DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 36: Warranties And Technical Support
User Manual IO-Link / Modbus TCP Slave Industrial Electronic Devices Document code: MN67863_ENG Revision 1.000 Page 36 of 36 WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
