6. Help and other information

5. Pull out the hexagon wrench again.
24
6. Put on the cover.
25
26
7. Turn the cover clockwise.
27
9 The cover snaps into place with one click.
The electronic thumb turn is installed.
9
Functional test
1. Turn and pull the escape thumb-turn to check that it is
properly locked in position.
2. Check that you can unlock the door with the escape
thumb-turn.
9 Escape thumb turn is installed.
6. Help and other information
Information material/documents
https://www.simons-voss.com/en/documents.html
https://www.smartintego.com/int/home/infocenter/
documentation
54 / 120 | EN
