53 / 120 | EN
Re-fitting the electronic thumb-turn
1.5 mm hexagonal wrench available.
ü
1. Align the thumb turn mount horizontally.
19
2. Attach the thumb turn.
20
21
Use the supplied hexagonal wrench.
The special tool is supplied with a hexagonal wrench.
Use this hexagonal wrench to mount and dismount the

electronic thumb turn.
3. Insert the hexagonal wrench into the hole provided until
it stops.
22
4. Turn the hex key 270 degrees clockwise.
23
5. Installation on the removed cylinder (anti-
NOTE
clockwise unlocking)
