4. Installation on fitted cylinder (clockwise un-
locking)
4. Installation on fitted cylinder (clockwise un-
locking)
Removing the mechanical thumb-turn
Special tool available.
ü
1. Align the thumb turn horizontally.
3
2. Attach the special tool.
3. Align the special tool so that the logo is parallel to the
recess.
4
4. At the same time turn the special tool and the thumb
turn counterclockwise.
5. Remove the special tool and the thumb turn at the same
time.
The mechanical thumb turn is disassembled.
9
Installing the escape thumb-turn
1.5 mm hexagonal wrench available.
ü
1. Insert the 1.5 mm hex key into the escape thumb turn.
5
2. Turn the hex key fully clockwise until it comes to a stop.
Escape thumb turn clicks.
9
