49 / 120 | EN
6
3. Pull out the hexagon wrench again.
4. Place the escape thumb turn on the cylindrical shaft.
7
5. Turn the escape thumb-turn clockwise until it engages.
8
Functional test
1. Turn and pull the escape thumb-turn to check that it is
properly locked in position.
2. Check that you can unlock the door with the escape
thumb-turn.
Escape thumb turn is installed.
9
5. Installation on the removed cylinder (anti-
clockwise unlocking)
Removing the mechanical thumb-turn
Special tool available.
ü
1. Align the thumb turn horizontally.
3
2. Attach the special tool.
3. Align the special tool so that the logo is parallel to the
