Digital Cylinder AX (Z5) Modularity
9 Bolt is protected against twisting.
12. Pull the spacer off again.
29
13. Push the halves together completely.
30
14. Refit the clip into the slot of the profile cylinder with the lug facing the
fastening screw.
31
15. Insert the cylinder into the clamping block so that the profile cylinder
and the thumb-turn lie flush in the recesses.
32
9 The lever of the clamping block is reinforced at one point with a
metal plate. The bracket that was previously inserted lies opposite
this metal plate.
16. Push the clamp block lever towards the base plate until the clamp is
fully seated in the profile cylinder.
33
9 Cylinder AX is shortened.

6. Combine CO cylinders to FD

34
You can assemble a freely rotating AX cylinder from two AX comfort
cylinders.
ü Extractor for releasing the clamp
ü Spacer for aligning the extension bolt
ü Clamp block for pressing in the clamp
1. Place the first comfort cylinder AX in the thumb-turn assembly tool with
the mechanical thumb-turn facing upwards.
35
2. Hook the tip of the extractor into the clamp.
36
3. Lever the clamp out of the profile cylinder by moving the extractor to
the centre of the cylinder.
37
4. Pull the clamp completely out of the profile cylinder.
38
5. Disassemble the two cylinder halves.
39
9 First cylinder half prepared with centre piece and tappet piece.
6. Place the second comfort cylinder AX in the thumb-turn assembly tool
with the electronic thumb-turn facing upwards.
40
7. Hook the tip of the extractor into the clamp.
41
8. Lever the clamp out of the profile cylinder by moving the extractor to
the centre of the cylinder.
42
9. Pull the clamp completely out of the profile cylinder.
43
10. Disassemble the two cylinder halves.
44
9 Second cylinder half prepared without centre piece.
11. Place the first cylinder half on the second cylinder half.
45
12. Refit the clip into the slot of the profile cylinder with the lug facing the
fastening screw.
46
EN
13. Insert the cylinder into the clamping block so that the profile cylinder
and the thumb-turn lie flush in the recesses.
47
The lever of the clamping block is reinforced at one point with a
9
metal plate. The bracket that was previously inserted lies opposite
this metal plate.
14. Push the clamp block lever towards the base plate until the clamp is
fully seated in the profile cylinder.
48
9 Freely rotating cylinder fully assembled.

7. Reduce CO cylinders to HZ

49
You can use a special centre piece to assemble a half cylinder from an AX
comfort cylinder or a freely rotating cylinder.
ü Extractor for releasing the clamp
Spacer for aligning the extension bolt
ü
Clamp block for pressing in the clamp
ü
Half Cylinder Center Section
ü
1. Place the Cylinder AX in the thumb-turn assembly tool with the elec-
tronic thumb-turn facing upwards.
50
2. Hook the tip of the extractor into the clamp.
51
3. Lever the clamp out of the profile cylinder by moving the extractor to
the centre of the cylinder.
52
4. Pull the clamp completely out of the profile cylinder.
5. Disassemble the two cylinder halves.
53
9 First cylinder half prepared without centre piece.
6. Place the spacer on the half-cylinder centre piece.
54
7. Screw in a suitable extension bolt with the extractor until it rests on the
spacer.
55
8. Place the prepared cylinder half in the thumb-turn assembly tool.
56
9. Place the half cylinder centre piece on the prepared cylinder half.
57
Extension bolt is protected against twisting.
9
10. Pull the spacer off again.
58
11. Push the cylinder parts together completely.
59
12. Refit the clip into the slot of the profile cylinder with the lug facing the
fastening screw.
60
13. Insert the cylinder into the clamping block so that the profile cylinder
and the thumb-turn lie flush in the recesses.
61
9 The lever of the clamping block is reinforced at one point with a
metal plate. The bracket that was previously inserted lies opposite
this metal plate.
14. Push the clamp block lever towards the base plate until the clamp is
fully seated in the profile cylinder.
62
Half cylinder AX is fully assembled.
9
6. Combine CO cylinders to FD
