Mecmesin VortexPro Operating Manual page 9

5
Unpacking and parts supplied
5.1
Inspection and unpacking
Important! If any damage is discovered, do not proceed with the installation and contact your local Important!
supplier immediately who will decide the most appropriate action and rectify the situation as quickly
as possible.
Before installing or operating the VortexPro system ensure that no visible damage has occurred during the
shipping of the device
5.2
Packaging
We strongly recommend that the packaging is retained, as this can be useful if the machine needs to be returned
for calibration or shipped to another location.
Parts supplied with the test stand, details the parts that should be included with your test stand. Please contact Parts supplied
Mecmesin or your authorised distributor if any items are missing or damaged.
5.3
Moving the test stand
The unpackaged weights of the test stand is listed in the specification table. Do not try to lift heavy
loads unaided. It is advised to use suitable lifting equipment and follow safe handling guidelines
when moving your VortexPro system.
5.4
Parts supplied
Please see the table below for the list of parts supplied with the VortexPro test stand.
Item Item
VortexPro test stand
Interchangeable Enhanced Torque Sensor (ETS)
VortexPro Touch console and test stand fixing bracket (optional)
2 metre USB-A to USB-B data cable
M2 Allen/Hex key
Allen/Hex key set (2.5 mm, 3 mm, 4 mm, 5mm)
Mains cable pack (for UK, Europe, and USA)
VectorPro software key
Document: A Guide to Safe Use of Mecmesin Mains Powered Test Systems
Online Manual Information Guide
5.5
Accessories
For a full range of accessories, please go to the Mecmesin website (
distributor.
w ww.mecmesin.com) or contact
Quantity Quantity
1
(depd on order)
(optional)
1
1
1
1
1
1
1
your local
9
