8
Settings
8.1

Jog settings

Within the jog settings menu, you can configure the jog speed limits while in jog mode. Below is a detailed
breakdown of each setting and the options available for each setting.
Setting Setting Action Action
Clockwise speed Configure the jog speed in a clockwise direction
Anticlockwise speedConfigure the jog speed in an anticlockwise direction
Set the timeout (in minutes) that the machine will keep the motor drive engaged,
before the motor drive is disabled. The load applied to the torque sensor must reach
at least 25% of the sensor capacity before the timeout activation is applied. At the
end of the timeout period, the 'Jog Active' menu screen is automatically switched
back to the 'Ready to Test' menu screen.
Jog timeout period
For example:
A VortexPro stand fitted with a 6 N.m torque sensor must reach 1.5 N.m in either
direction before the timeout activation is applied. Loads below the 25% limit will not
activate the timeout and the stand will actively hold the load applied.
Clockwise torque
Configure the clockwise torque limit while in jog mode.
limit
Anticlockwise
Configure the anticlockwise torque limit while in jog mode.
torque limit
8.2
Units
Within the units menu, you can configure the test stands units for displacement and speed.
SettingUnits available Setting Units available
Angle rev, deg
Speed rev/min, rev/sec, deg/min, deg/sec
N.m, N.cm, mN.m, gf.cm, kgf.cm, kgf.m, lbf.ft, lbf.in,
Torque
ozf.in
8.3
Edit test
For more information relating to 'Start Direction' and 'Move to Start', please see Operation
Sequence and Move to Start Sequence
8.3.1
Cycle (by Angular Displacement)
In a cyclic test, the spindle moves between two reference angles that are relative to tared zero.
Setting Setting
Cycle count
Clockwise speed
Anticlockwise
speed
Clockwise angle
Anticlockwise angle
below
Move to Start as well as the VectorPro software manual.
Options Options
0-9999
0-30 rev/min (0 to 180 deg/s)
0-30 rev/min (0 to 180 deg/s)
A positive value is clockwise from tared zero and a negative value is below
A positive value is clockwise from tared zero and a negative value is
Range Range
0.1 to
30
rev/min
0.1 to
30
rev/min
1 to 59
minutes
0 to
125%
torque
cell
capacity
0 to
125%
torque
cell
capacity
Operation
21
