Settings Menu - Mecmesin VortexPro Operating Manual

7.4.3
Pause/Stopped
Icon Icon
7.4.4
Jog mode
Icon Icon
7.4.5

Settings menu

Icon Icon
Emergency stop button pushed: Message: 'Emergency Stop!!! Emergency stop button pushed: Message:
stop to regain control and remedy the situation before resuming testing. Note there is
no on-screen icon for the emergency stop.
Action Action
Continue test sequence Continue test sequence .
Stop test Stop test - Shown when the Pause button is pressed. This ends the test at this point.
Move to the home position (start position from the beginning of the previous test) Move to the home position (start position from the beginning of the previous test) -
This icon is only visible after pressing the 'Stop
Exit to the test ready screen, leaving the crosshead in its current position - This icon is Exit to the test ready screen, leaving the crosshead in its current position
only visible after pressing the 'Stop
Action Action
Zero (tare) all system values. Zero (tare) all system values.
Move the lower spindle in a clockwise direction at the set jog speed. Move the lower spindle in a clockwise direction at the set jog speed.
Move the lower spindle in a anti-clockwise direction at the set jog speed. Move the lower spindle in a anti-clockwise direction at the set jog speed.
Go back to the previous screen. Go back to the previous screen.
Action Action
Confirm selection (or press the centre scroll wheel button). Confirm selection (or press the centre scroll wheel button).
Navigate up a menu selection or value (or turn the wheel clockwise). Navigate up a menu selection or value (or turn the wheel clockwise).
Navigate down a menu selection or value (or turn the wheel anticlockwise). Navigate down a menu selection or value (or turn the wheel anticlockwise).
Go back to the previous screen. Go back to the previous screen.
Emergency Stop!!!'. Release the emergency
Stop' button.
Stop' button.
