buttons (highlighted below).
1 1 Enter Jog Mode
2 2 Jog keys 'Clockwise' and 'Anti-clockwise'
The scroll wheel can function as a speed controller. The jog buttons move the spindle at preset speeds
(configured in the 'Jog Settings' menu, shown below). Rotating the wheel clockwise while holding a jog button
increases the speed, and rotating it anticlockwise decreases the speed.
VortexPro test stands also include a precision jog mode: rotating the scroll wheel while holding the central scroll
wheel button moves the test stand at its minimum speed. This is particularly useful when fitting specimens into
grips, for example.
7.2.3

Navigation and selection

The scroll wheel and central button can be used to navigate selection menus.
1 Confirm selection - Tick selector button/scroll wheel central button
2 Navigate up/down menu options - Up/down selector buttons/scroll wheel
Once in a selection menu the scroll wheel (2) or up/down keys (2) can cycle through the selections and values.
To confirm a selection, use either the tick selector button (1) or the scroll wheel central button (1).
