Flowmeter Proline 200 PROFINET with Ethernet-APL
5.2.5 Terminal assignment
Transmitter
Maximum number of terminals
Terminals 1 to 6:
Without integrated overvoltage protection
1 Output 1 (passive): supply voltage and signal transmission
2 Output 2 (passive): supply voltage and signal transmission
3 Input (passive): supply voltage and signal transmission
4 Ground terminal for cable shield
Order code for "Output"
1)
Option S
1) PROFINET with Ethernet-APL with integrated reverse polarity protection.
Endress+Hauser
3 2
5 6 3 4
+ – + –
Output 1
1 (+) 2 (-)
PROFINET with Ethernet-
APL
1 4
1 2
+ –
Maximum number of terminals for order code for
"Accessory mounted", option NA "Overvoltage
protection"
• Terminals 1 to 4:
With integrated overvoltage protection
• Terminals 5 to 6:
Without integrated overvoltage protection
Terminal numbers
Output 2
3 (+) 4 (-)
-
Electrical connection
A0033475
Input
5 (+) 6 (-)
-
