Products
Brief Operating Instructions
Flowmeter
Proline 200
Transmitter with vortex flow sensor
PROFINET with Ethernet-APL
These instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Brief Operating Instructions part 2 of 2: Transmitter
Contain information about the transmitter.
Brief Operating Instructions part 1 of 2: Sensor →  3
Solutions
Services

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Proline 200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Endress+Hauser Proline 200

  • Page 1 Services KA01545D/06/EN/01.22-00 71589695 2024-06-19 Brief Operating Instructions Flowmeter Proline 200 Transmitter with vortex flow sensor PROFINET with Ethernet-APL These instructions are Brief Operating Instructions; they are not a substitute for the Operating Instructions pertaining to the device. Brief Operating Instructions part 2 of 2: Transmitter Contain information about the transmitter.
  • Page 2 Flowmeter Proline 200 PROFINET with Ethernet-APL Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...
  • Page 3 Flowmeter Proline 200 PROFINET with Ethernet-APL Brief Operating Instructions for flowmeter Brief Operating Instructions for flowmeter The device consists of a transmitter and a sensor. The process of commissioning these two components is described in two separate manuals that together form the Brief Operating Instructions for the flowmeter: •...
  • Page 4: Table Of Contents

    Table of contents Flowmeter Proline 200 PROFINET with Ethernet-APL Table of contents About this document ............. . 5 Symbols used .
  • Page 5: About This Document

    Flowmeter Proline 200 PROFINET with Ethernet-APL About this document About this document Symbols used 1.1.1 Safety symbols DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury.
  • Page 6 About this document Flowmeter Proline 200 PROFINET with Ethernet-APL Symbol Meaning Potential equalization connection (PE: protective earth) Ground terminals that must be connected to ground prior to establishing any other connections. The ground terminals are located on the interior and exterior of the device: •...
  • Page 7: Safety Instructions

    Flowmeter Proline 200 PROFINET with Ethernet-APL Safety instructions Safety instructions Requirements for the personnel The personnel must fulfill the following requirements for its tasks: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task. ‣...
  • Page 8: Workplace Safety

    Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.
  • Page 9: It Security

    Flowmeter Proline 200 PROFINET with Ethernet-APL Product description IT security Our warranty is valid only if the product is installed and used as described in the Operating Instructions. The product is equipped with security mechanisms to protect it against any inadvertent changes to the settings.
  • Page 10: Mounting The Transmitter Of The Remote Version

    Mounting Flowmeter Proline 200 PROFINET with Ethernet-APL Mounting the transmitter of the remote version CAUTION Ambient temperature too high! Danger of electronics overheating and housing deformation. ‣ Do not exceed the permitted maximum ambient temperature . ‣ If operating outdoors: Avoid direct sunlight and exposure to weathering, particularly in warm climatic regions.
  • Page 11: Turning The Transmitter Housing

    Flowmeter Proline 200 PROFINET with Ethernet-APL Mounting 4.1.2 Pipe mounting 20 70 … ( 0.79 to 2.75) SW 13 A0033486  2 mm (in) Turning the transmitter housing To provide easier access to the connection compartment or display module, the transmitter housing can be turned.
  • Page 12: Turning The Display Module

    Mounting Flowmeter Proline 200 PROFINET with Ethernet-APL Turning the display module The display module can be turned to optimize display readability and operability. 3 mm A0032238 Loosen the securing clamp of the electronics compartment cover using an Allen key. Unscrew cover of the electronics compartment from the transmitter housing.
  • Page 13: Electrical Connection

    Flowmeter Proline 200 PROFINET with Ethernet-APL Electrical connection Electrical connection Electrical safety In accordance with applicable national regulations. Connecting requirements 5.2.1 Required tools • For cable entries: Use corresponding tools • For securing clamp: Allen key 3 mm • Wire stripper •...
  • Page 14 Electrical connection Flowmeter Proline 200 PROFINET with Ethernet-APL 5.2.3 Connecting cable for remote version Connecting cable (standard) Standard cable 2 × 2 × 0.5 mm (22 AWG) PVC cable with common shield (2 pairs, pair-stranded) Flame resistance According to DIN EN 60332-1-2...
  • Page 15 Flowmeter Proline 200 PROFINET with Ethernet-APL Electrical connection Wire cross-section 0.8 mm (AWG 18) Loop resistance (direct 44 Ω/km current) Characteristic impedance at 100 Ω ±20% 31.25 kHz Attenuation constant at 39.0 3 dB/km Capacitive asymmetry 2 nF/km Envelope delay distortion 1.7 ms/km...
  • Page 16 Electrical connection Flowmeter Proline 200 PROFINET with Ethernet-APL hazardous areas (EEx ia IIC) is possible. The actual number of users must be determined during the planning stage. Bus termination Always terminate the start and end of each fieldbus segment with a bus terminator.
  • Page 17 Flowmeter Proline 200 PROFINET with Ethernet-APL Electrical connection 5.2.5 Terminal assignment Transmitter – – – A0033475 Maximum number of terminals Maximum number of terminals for order code for Terminals 1 to 6: "Accessory mounted", option NA "Overvoltage Without integrated overvoltage protection protection"...
  • Page 18 Electrical connection Flowmeter Proline 200 PROFINET with Ethernet-APL Connecting cable for remote version Transmitter and sensor connection housing In the case of the remote version, the sensor and transmitter are mounted separately from on another and connected by a connecting cable. Connection is performed via the sensor connection housing and the transmitter housing.
  • Page 19 Flowmeter Proline 200 PROFINET with Ethernet-APL Electrical connection ~20° 8 mm A0041608 Loosen the securing clamp of the transmitter housing. Turn the transmitter housing clockwise by approx. 20°. NOTICE The connection board of the wall housing is connected to the electronics board of the transmitter via a signal cable! ‣...
  • Page 20 Electrical connection Flowmeter Proline 200 PROFINET with Ethernet-APL Connecting cable (standard, reinforced) – – A0033476  3 Terminals for connection compartment in the transmitter wall holder and the sensor connection housing Terminals for connecting cable Grounding via the cable strain relief...
  • Page 21 Flowmeter Proline 200 PROFINET with Ethernet-APL Electrical connection 5.2.7 Shielding and grounding Optimal electromagnetic compatibility (EMC) of the fieldbus system can be guaranteed only if the system components and, in particular, the lines are shielded and the shield forms as complete a cover as possible.
  • Page 22 Electrical connection Flowmeter Proline 200 PROFINET with Ethernet-APL A0047536  4 Connection example for PROFINET with Ethernet-APL Cable shield Measuring device Local grounding Potential equalization Trunk or TCP Field switch 5.2.8 Requirements for the supply unit Supply voltage Transmitter An external power supply is required for each output.
  • Page 23: Connecting The Measuring Device

    Flowmeter Proline 200 PROFINET with Ethernet-APL Electrical connection 5.2.9 Preparing the measuring device Carry out the steps in the following order: Mount the sensor and transmitter. Sensor connection housing: Connect connecting cable. Transmitter: Connect connecting cable. Transmitter: Connect signal cable and cable for supply voltage.
  • Page 24 Electrical connection Flowmeter Proline 200 PROFINET with Ethernet-APL Connection via terminals 3 mm 20 mm 10 (0.4) mm (in) A0048825 Loosen the securing clamp of the connection compartment cover. Unscrew the connection compartment cover. Push the cable through the cable entry . To ensure tight sealing, do not remove the sealing ring from the cable entry.
  • Page 25 Flowmeter Proline 200 PROFINET with Ethernet-APL Electrical connection Connection via device plug A0032229 ‣ Plug in the device plug and tighten firmly. Removing a cable 0,5 × 3,5 mm A0048822 ‣ To remove a cable from the terminal, use a flat-blade screwdriver to push the slot between the two terminal holes while simultaneously pulling the cable end out of the terminal.
  • Page 26 Electrical connection Flowmeter Proline 200 PROFINET with Ethernet-APL The following sequence of steps is recommended : Mount the sensor and transmitter. Connect the . Connect the transmitter. How the connecting cable is connected in the transmitter housing depends on the measuring device approval and the version of the connecting cable used.
  • Page 27 Flowmeter Proline 200 PROFINET with Ethernet-APL Electrical connection A0034171  5 Sample graphic Connecting cable (standard, reinforced) Guide the connecting cable through the cable entry and into the connection housing (if using a connecting cable without an M12 device plug, use the shorter stripped end of the connecting cable).
  • Page 28 Electrical connection Flowmeter Proline 200 PROFINET with Ethernet-APL Reverse the removal procedure to reassemble the connection housing. Connecting the transmitter Connecting transmitter via plug A0034172 ‣ Connect the plug. Connecting transmitter via terminals 3 mm A0034173 Loosen the securing clamp of the electronics compartment cover.
  • Page 29 Flowmeter Proline 200 PROFINET with Ethernet-APL Electrical connection TX 10 8 mm A0034174 Loosen the locking screw of the transmitter housing. Loosen the securing clamp of the transmitter housing. ~15° A0034175  6 Sample graphic Turn the transmitter housing to the right until it reaches the marking.
  • Page 30 Electrical connection Flowmeter Proline 200 PROFINET with Ethernet-APL A0034176  7 Sample graphic A0034177  8 Sample graphic Connecting cable (standard, reinforced) Disconnect the signal cable from the connection board of the wall housing . by pressing in the locking clip on the connector. Remove the transmitter housing.
  • Page 31: Ensuring The Degree Of Protection

    Flowmeter Proline 200 PROFINET with Ethernet-APL Electrical connection 11. Connect the cable shield via the cable strain relief. 12. Tighten the screws for the cable strain relief using a torque in the range of 1.2 to 1.7 Nm. 13. Reverse the removal procedure to reassemble the transmitter housing.
  • Page 32: Post-Connection Check

    Electrical connection Flowmeter Proline 200 PROFINET with Ethernet-APL Dry, clean or replace the seals if necessary. Tighten all housing screws and screw covers. Firmly tighten the cable glands. To ensure that moisture does not enter the cable entry: Route the cable so that it loops down before the cable entry ("water trap").
  • Page 33: Operation Options

    Flowmeter Proline 200 PROFINET with Ethernet-APL Operation options Operation options Overview of operation options A0046117 Automation system, e.g. Simatic S7 (Siemens) Standard Ethernet switch, e.g. Scalance X204 (Siemens) Computer with web browser (e.g. Internet Explorer) for accessing the integrated web server or computer with operating tool (e.g.
  • Page 34: Structure And Function Of The Operating Menu

    Operation options Flowmeter Proline 200 PROFINET with Ethernet-APL Structure and function of the operating menu 6.2.1 Structure of the operating menu Operating menu for operators and maintenances Language Operation task-oriented Setup Diagnostics Operating menu for experts Expert function-oriented A0014058-EN  9 Schematic structure of the operating menu 6.2.2...
  • Page 35: Access To The Operating Menu Via The Local Display

    Flowmeter Proline 200 PROFINET with Ethernet-APL Operation options Access to the operating menu via the local display X X X X X X 19.184 mA 12.5 X X X X X X Language à English 20.50 Deutsch Español Français Xxxxxxx...
  • Page 36 Operation options Flowmeter Proline 200 PROFINET with Ethernet-APL 6.3.1 Operational display Explanatory symbols for the measured value Status area • Depends on the device version, e.g.: The following symbols appear in the status area of the • : Volume flow operational display at the top right: •...
  • Page 37 Flowmeter Proline 200 PROFINET with Ethernet-APL Operation options Numeric editor Confirms selection. Moves the input position one position to the left. Exits the input without applying the changes. Inserts decimal separator at the cursor position. Inserts minus sign at the cursor position.
  • Page 38: Access To The Operating Menu Via The Operating Tool

    System integration Flowmeter Proline 200 PROFINET with Ethernet-APL Keys and meaning Plus/Enter key combination (press and hold down the keys simultaneously) Increases the contrast (darker setting). Minus/Plus/Enter key combination (press the keys simultaneously) With an operational display: Enables or disables the keypad lock (only SD02 display module).
  • Page 39: Switching On The Measuring Device

    Flowmeter Proline 200 PROFINET with Ethernet-APL Commissioning Switching on the measuring device ‣ After a successful function check, switch on the measuring device.  After a successful startup, the local display switches automatically from the startup display to the operational display.
  • Page 40: Protecting Settings From Unauthorized Access

    Commissioning Flowmeter Proline 200 PROFINET with Ethernet-APL The desired units can be selected in the System units submenu. The wizards systematically guide the user through all the parameters required for configuration, such as parameters for measurement or outputs. The wizards available in the particular device can vary on account of the device version (e.g.
  • Page 41 Flowmeter Proline 200 PROFINET with Ethernet-APL Commissioning When pressure measured value is read in In the Steam calculation mode parameter, select the Automatic (p-/T-compensated) option. If pressure measured value is not read in: In the Steam calculation mode parameter, select the Saturated steam (T- compensated) option.
  • Page 42 Commissioning Flowmeter Proline 200 PROFINET with Ethernet-APL In the Reference temperature parameter, enter the fluid temperature associated with the reference density. In the Linear expansion coefficient parameter, enter the expansion coefficient of the fluid. In the Specific heat capacity parameter, enter the heat capacity of the fluid.
  • Page 43 Flowmeter Proline 200 PROFINET with Ethernet-APL Commissioning Gas mixture Forming gas for steel mills and rolling mills, e. g. N Select medium Navigation: Setup → Medium selection Call up the Medium selection wizard. In the Select medium parameter, select the Gas option.
  • Page 44 In the Reference temperature parameter enter the temperate for calculating the reference density. Endress+Hauser recommends the use of active pressure compensation. This fully rules out the risk of measured errors due to pressure variations and incorrect entries . Natural gas...
  • Page 45 12. In the Relative density parameter, enter the relative density of the natural gas. Endress+Hauser recommends the use of active pressure compensation. This fully rules out the risk of measured errors due to pressure variations and incorrect entries .
  • Page 46: Diagnostic Information

    Diagnostic information Flowmeter Proline 200 PROFINET with Ethernet-APL In the Reference density parameter, enter the reference density of the fluid. In the Reference pressure parameter, enter the reference pressure of the fluid. In the Reference temperature parameter, enter the fluid temperature associated with the reference density.
  • Page 47 Flowmeter Proline 200 PROFINET with Ethernet-APL Diagnostic information X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage Diagnostics 2 Diagnostics 3 Supply voltage...
