Endress+Hauser Proline 200 Brief Operating Instructions page 14

Electrical connection
5.2.3 Connecting cable for remote version
Connecting cable (standard)
Standard cable
Flame resistance
Oil resistance
Shielding
Cable length
Continuous operating
temperature
1) UV radiation may cause damage to the outer jacket of the cable. Protect the cable from exposure to sun as much
as possible.
Connecting cable (armored)
Cable, armored
Flame resistance
Oil resistance
Shielding
Strain relief and
reinforcement
Cable length
Continuous operating
temperature
1) UV radiation may cause damage to the outer jacket of the cable. Protect the cable from exposure to sun as much
as possible.
5.2.4 Fieldbus cable specification
Cable type
In accordance with IEC 61158-2 (MBP), cable type A is recommended. Cable type A has a
cable shielding that guarantees adequate protection from electromagnetic interference and
thus the most reliable data transfer.
The electrical data of the fieldbus cable have not been specified. but determine important
characteristics of the design of the fieldbus, such as distances bridged, number of users,
electromagnetic compatibility, etc.
Cable type
Cable structure
14
2 × 2 × 0.5 mm 2 (22 AWG) PVC cable with common shield (2 pairs, pair-stranded)
According to DIN EN 60332-1-2
According to DIN EN 60811-2-1
Galvanized copper-braid, opt. density approx. 85 %
5 m (15 ft), 10 m (30 ft), 20 m (60 ft), 30 m (90 ft)
When mounted in a fixed position: –50 to +105 °C (–58 to +221 °F); when cable can
move freely: –25 to +105 °C (–13 to +221 °F)
2
2 × 2 × 0.34 mm (22 AWG) PVC cable with common shield (2 pairs, pair-stranded)
and additional steel-wire braided sheath
According to DIN EN 60332-1-2
According to DIN EN 60811-2-1
Galvanized copper-braid, opt. density approx. 85%
Steel-wire braid, galvanized
10 m (30 ft), 20 m (60 ft), 30 m (90 ft)
When mounted in a fixed position: –50 to +105 °C (–58 to +221 °F); when cable can
move freely: –25 to +105 °C (–13 to +221 °F)
A
Twisted, shielded twin-core cable
Flowmeter Proline 200 PROFINET with Ethernet-APL
1)
1)
