Anybus Communicator
Modbus TCP Client
Connection to subnetwork Modbus TCP client device
• LED C for PROFINET network
• LED B for EtherNet/IP, PROFIBUS, and EtherCAT networks
Operation status
Off
Red, flashing
Red, solid
Green, solid
Security switch - LED D
Operation status
Off
Green
Fatal Error and Exception Error
Fatal error: A fatal error causes the Communicator firmware application to crash in an
uncontrolled manner.
Exception error: An exception error causes the Communicator to enter a controlled error
state. The Communicator firmware application is still running.
LED Fatal error
A Red, solid
B Red, solid
C Red, solid
D Off
Page 28 of 32
™
- Common Ethernet to
Description
No IP address.
At least one connection error or timeout.
IP address conflict detected, or FATAL event.
No connections errors or timeouts.
Description
No power/Security switch is unlocked/Exception/Fatal error
Security switch is locked
Fatal Error and Exception Error
Exception error
Red, solid
Off
Off
Off
