Connect to Power

Power Connector Pinout

Power port
SP3311 Version 1.0
®
Anybus
Communicator
Pin
Description
1
12-30 VDC Power
Connector
2
Ground (GND)
3
Functional Earth (FE)
™
- Common Ethernet to
Modbus TCP Client
Page 15 of 32
