INSTALLATION AND USE

3.1

NOTICE

1. Place the ARM CONTROLLER on a stable surface.

NOTICE

2. Make sure that the safety key is in the OFF position.

3. Make sure that the emergency stop button is unlatched. If latched, turn the

button a quarter in the clockwise direction to release it.

4. Connect the PowerCon TRUE1 power cable to the power input of the controller.

Connect the other end to a power outlet.

5. Connect the correct cables between the ARM CONTROLLER, the SFX machines,

the control equipment and ARM SYSTEM components (if applicable). Check

the following variants for connection details.

MAGICFX

SFX SAFETY ARM CONTROLLER — User and Installation Manual

Do not connect the ARM CONTROLLER to machines that are not

compatible with the ARM SYSTEM. Failure to do so could cause

damage to the equipment.

Do not use RJ45 cables in the ARM SYSTEM that come from any

other system than the ARM SYSTEM, carrying a different data pro-

tocol. Failure to do so could cause damage to the equipment.

Do not use more than one ARM CONTROLLER in a single ARM

SYSTEM. Failure to do so could cause damage to the equipment

and malfunction of the emergency stop.

Insert a TERMINATOR in the last ARM output of each line to close

the safety circuit. The ARM SYSTEM will not work when a line

remains open.

Position the ARM CONTROLLER in such a way that it is readily

accessible by the operator and that it cannot be actuated

accidentally.
