- Page 1 USER AND INSTALLATION MANUAL ENGLISH CONTROLLER. ® PART01882 SFX SAFETY rev 02-00...
-
Page 2: Disclaimer
Read this manual carefully before installing and/or using this product. Failure to read the manual and to follow the printed instructions may lead to personal injury and/or damage to the product. © 2022 MAGICFX ® All rights reserved. Nothing from this publication may be copied, reproduced and/or published by means of printing, photocopying or by any other means, without the prior written approval of MAGIC FX. -
Page 3: Table Of Contents
Install the controller Arm the system Use the emergency stop Release the emergency stop and perform a reset Disarm the system Maintenance Troubleshooting Correct disposal EC Declaration of Conformity MAGICFX SFX SAFETY ARM CONTROLLER — User and Installation Manual ®... -
Page 4: Introduction
Are familiar with and abide by the applicable local, national and international laws and regulations. LANGUAGE This document contains the original instructions in English. In case you require other languages please contact MAGIC FX. MAGICFX SFX SAFETY ARM CONTROLLER — User and Installation Manual ®... -
Page 5: Other Arm System Documentation
COMBINER 19” RACK User and Installation Manual PART02292 Other ARM SYSTEM documentation ABBREVIATIONS Abbreviation Description Special effects Digital Multiplex Remote Device Management ARM SYSTEM MAGICFX SFX SAFETY ARM SYSTEM ® ARM CONTROLLER MAGICFX SFX SAFETY ARM CONTROLLER ® E-STOP MAGICFX SFX SAFETY E-STOP ®... -
Page 6: Description
SYSTEM EXTENSIONS The ARM SYSTEM can be extended with additional control and signaling devices, such as an external emergency stop device called the E-STOP . MAGICFX SFX SAFETY ARM CONTROLLER — User and Installation Manual ®... -
Page 7: Main Parts
- The emergency stop button on the ARM CONTROLLER was actuated. - A line interruption outside of the controller (red LED) was resolved. Normal operation: You can arm/disarm the system. LED indicators MAGICFX SFX SAFETY ARM CONTROLLER — User and Installation Manual ®... -
Page 8: Product Identification
(version 02). Please refer to the correct manual (version 01) for instructions or contact MAGIC FX if you want to update your controller. TECHNICAL DATA Product Product Name MAGICFX SFX SAFETY ARM CONTROLLER ® Product Code MFX3220 Product Type... -
Page 9: Accessories
MAGICFX® SFX SAFETY TERMINATOR MFX3226 MAGICFX® SFX SAFETY DMX INJECTOR - cable 25 cm SFX3201 MAGICFX® SFX SAFETY LABEL - size small 50 x 25 mm SFX3202 MAGICFX® SFX SAFETY LABEL - size medium 75 x 50 mm MFX0340 SFX SAFETY ARM Data cable (etherCON) - 1 meter... -
Page 10: Safety
Make sure that each ARM component, control device and SFX WARNING machine in the ARM SYSTEM is correctly installed in compliance with the instructions from the corresponding user and installation manuals from MAGIC FX. MAGICFX SFX SAFETY ARM CONTROLLER — User and Installation Manual ®... -
Page 11: Operation
As a supervisor, only provide safety keys of the ARM CONTROLLER NOTICE to authorised personnel. Remove the safety key and store it in a safe place when you NOTICE leave the ARM CONTROLLER unattended. MAGICFX SFX SAFETY ARM CONTROLLER — User and Installation Manual ®... -
Page 12: Installation And Use
Connect the other end to a power outlet. 5. Connect the correct cables between the ARM CONTROLLER, the SFX machines, the control equipment and ARM SYSTEM components (if applicable). Check the following variants for connection details. MAGICFX SFX SAFETY ARM CONTROLLER — User and Installation Manual ®... - Page 13 With an ARM data (EtherCON) cable, both ARM connectors of the ARM CONTROLLER are connected to a SFX machine or an ARM SYSTEM component. ARM CONTROLLER SFX MACHINE E-STOP terminator POWER SFX MACHINE terminator MAGICFX SFX SAFETY ARM CONTROLLER — User and Installation Manual ®...
- Page 14 Remove the safety key and store it in a safe place when you NOTICE leave the ARM CONTROLLER unattended. MAGICFX SFX SAFETY ARM CONTROLLER — User and Installation Manual ®...
-
Page 15: Arm The System
RELEASE THE EMERGENCY STOP AND PERFORM A RESET 1. Confirm that the safety key is in the OFF position. 2. Confirm that the emergency situation has been resolved. MAGICFX SFX SAFETY ARM CONTROLLER — User and Installation Manual ®... -
Page 16: Disarm The System
Do not replace parts yourself; always consult MAGIC FX. DANGER TROUBLESHOOTING Always contact MAGIC FX if any malfunctions or errors occur that cannot be solved with the instructions as described in this manual. MAGICFX SFX SAFETY ARM CONTROLLER — User and Installation Manual ®... -
Page 17: Correct Disposal
Please contact your local authority for further details of your nearest designated collection point. Penalties may be applicable for incorrect disposal of this waste, in accordance with your national legislation. MAGICFX SFX SAFETY ARM CONTROLLER — User and Installation Manual ®... -
Page 18: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY MAGICFX SFX SAFETY ARM CONTROLLER — User and Installation Manual ®... - Page 19 MAGICFX SFX SAFETY ARM CONTROLLER — User and Installation Manual ®...
- Page 20 WWW.MAGICFX.EU...
