1.4

PRODUCT IDENTIFICATION

NOTICE
1.5

TECHNICAL DATA

Product Product Name
Product Code
Product Type
Main
Length
Dimensions
Width
Height
Weight Weight
Package
Length
Width
Height
Packaged weight
Environment Minimum Temperature
Maximum Temperature
Humidity (Relative)
IEC 60529 (IP) Rating
Electrical
Voltage Input
Voltage Frequency
Power Consumption
Power Connector
ARM Connector
Controlling
Control Options
8 MAGICFX SFX SAFETY ARM CONTROLLER — User and Installation Manual
®
If the product name on the type plate of your controller shows
'FX-ARM CONTROLLER' instead of 'SFX SAFETY ARM CONTROLLER',
you have an old version of the ARM CONTROLLER. The old version
is not compatible with the ARM SYSTEM as described in this
manual (version 02). Please refer to the correct manual (version
01) for instructions or contact MAGIC FX if you want to update
your controller.
MAGICFX SFX SAFETY ARM CONTROLLER
®
MFX3220
SFX SAFETY
158 mm
180 mm
102 mm
1.9 kg
309 mm
364 mm
187 mm
2.7 kg
-10 °C
50 °C
20 % to 90 % (non condensing)
IP23
100 – 250 Vac
50 – 60 Hz
35 W
Neutrik powerCON TRUE1 (in)
®
Neutrik etherCON, RJ45 (in&out)
®
Manual
Type plate
6.2 in
7.1 in
4.0 in
4.2 lb
12.2 in
14.3 in
7.4 in
6 lb
14 °F
122 °F
Technical data
