4.5 TMCL Creator

The TMCL Creator can be used to develop standalone TMCL programs on the TMCM-1290. These TMCL
programs can be downloaded to the TMCM-1290 and then run standalone after power up. The central
part of the TMCL Creator is its main window with its own menu bar and the TMCL program editor. The
TMCL program editor mainly provides the functionality of a standard text editor with built-in syntax high-
lighting for TMCL. Here, TMCL programs can be entered and modi ed. After a program is entered, it can
be assembled, downloaded to the module, and run on the module.
For further information on the syntax of the TMCL programming language and the TMCL Creator tool,
refer to the TMCL-IDE user manual manual. Refer to the TMCM-1290 TMCL rmware manual to learn
more about using TMCL as a programming language.
Figure 11: TMCL Creator Example
