TMCM-1290-EVAL Evaluation Board • Hardware Version V1.00 | Rev 0, 01/24
2.1 First Start-Up
1. Make sure that the latest version of the TMCL-IDE V3.X is installed. Download the TMCL-IDE V3.X
from
https://www.analog.com/en/design-center/evaluation-hardware-and-software/motor-motion-
control-software/tmcl-ide.html.
2. Set the
IREF jumper JP1 and JP2
3. Set
jumper JP3
to external clock (EXT).
4. Connect the stepper motor phases to the TMCM-1290-EVAL
5. Connect TMCM-1290-EVAL
poperly terminated using a termination resistor at both ends, especially for longer buses.
NOTE
6. Power the module through the
after power up.
7. Open TMCL-IDE V3.X and connect the TMCM-1290-EVAL through RS485 to the computer. The default
baud rate is 115200 and default ID 1.
For Windows® 8 and higher, no driver is needed. On Windows 7 machines, the TMCL-IDE V3.X installs
the driver automatically.
Windows is a registered trademark of Microsoft, Corp.
Figure 1: Getting Started
according to the stepper motor rated current.
RS485 connector
to the PC using a RS485 adapter. The bus should be
Some RS485 adapters include the termination resistor. Refer to the manufac-
turer RS485 data sheet.
power supply
connector. The TMCM-1290 on-board green
motor
connector.
4/18
LED
blinks
