4
1.0

ST95 Uplink

The BrightTEK
provides remote wireless connectivity of Magnetrol
Orion Instruments
measurement sensors to the AMETEK cloud-enabled
BrightTEK web server, allowing remote data monitoring
and system processing.
The battery-powered uplink can be used to provide
power and monitoring to sensors in remote locations
and tank farms without the need to install wired data
and power connections, reducing installation cost.
They can also be added to existing (already wired)
sensors without interfering with existing PLC and DCS
systems to provide remote access to sensor data.
The ST95 Cellular Uplink Host can power and commu-
nicate with up to two 4-20mA Sensors. It is compati-
ble with either AT&T
certified intrinsically safe for Class 1 Division 1 Group
D locations once installed as outlined in this manual. It
can be installed with a standalone sensor or in a tank
farm environment supporting up to 12 ST95 Uplink Cli-
ents with one cellular connection.
WARNING: Read these installation and operation instruc-
tions carefully. Failure to follow these instruc-
tions may be dangerous or illegal.
Only qualified service personnel must install or service
this equipment or installation.
Record the model and serial numbers for future
reference.
ST95 Cellular Uplink Host by AMETEK
, Drexelbrook
and SWI
®
®
or Verizon
cellular services and
®
®
Model Number
Serial Number
41-622 BrightTEK
,
®
level
®
ST9x Operator Manual
