CASE DESIGN, CONT'D: POWER CORD & PLUG / LED LIGHT SWITCH LOCATIONS / LED LIGHTS
3. Power Cord and Plug
• Power cord and plug (for LED lights) is at case
rear (shown below).
• Caution! You must plugged in an approved outlet!
4. LED Light Switch Locations
• Cases with rear sliding doors have light switch in
column cover (for easy access at case rear).
• Cases with solid back rear plenums have light
switch in header.
• See illustrations below.
5. LED Lights
• LED lights are located at both header and
shelving of case (as shown below).
• Check that ALL of the light plugs are properly
connected to the LED light.
• Plug must be inserted ALL THE WAY into the
LED light orifice (with no gap) to work properly.
• See TROUBLESHOOTING section in manual
if LED lights malfunction.
LED Lights In
Shelving And
Header
Model NE4827DSSV
Shown With Rear Sliding
Doors Removed For
Illustrative Purposes Only.
Model NE4827DSSV Slide-In Unit (Shown)
May Not Exactly Reflect Every Feature or
Option of Your Particular Case.
LED Light
14
Plug
LED Light
Switch
Rear Sliding
Doors
Power Cord
And Plug
