CASE DESIGN, CONT'D: REAR SLIDING DOORS VS. REAR PANEL / DOOR OPERATION

6. Rear Sliding Doors vs. Rear Panel
• Self-service cases may have either rear panel or rear sliding (and removable) doors.
• Unit with rear sliding doors is shown below.
• To remove rear sliding doors, move doors toward center of case.
• Individually lift each door up toward the top of the case; pivot the bottom of the door out.
• Return doors to case in reverse order they were removed.
Model NE4827DSSV (Shown) May
Not Exactly Reflect Every Feature or
Option of Your Particular Case.
15
Rear Sliding
Doors
Power Cord
And Plug
