INSTALLATION, CONT'D: FIELD WIRE (OR PLUG IN) CASE / TURN ON LED LIGHTS

9. Field Wire (Or Plug In) Case / Turn on LED Lights
• Field-wired case or plug unit into outlet (if plug is present).
• Case will energize when properly field-wired (or plugged
into outlet).
• Turn on LED light switch at rear-left plenum.
Electrical / LED
Driver Box
Illustrations Shown Reflects Model
NM7255DSSV. It May Not Exactly
Reflect Every Feature or Option of
Your Particular Merchandiser.
LED Light
Switch
LED
Drivers
9
LED Light
Terminal
Field Access
Block
Box
