TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL)

CONDITION
Case Lights Check that light switch is in the ON position.
Not Working
• See CASE DESIGN, CONT'D: POWER CORD & PLUG / LED LIGHT SWITCH
LOCATIONS / LED LIGHTS section in manual for switch location (regardless of case
design).
If case is not hard-wired, check that power cord is properly connected to wall outlet.
Check that ALL of the light plugs are properly connected to the LED light.
• Plug must be inserted ALL THE WAY into the LED light orifice (with no gap).
• See illustrations below-left.
Power may not be reaching the case.
• Contact store management to have trained service provider perform troubleshooting.
• Troubleshooting to be performed by trained service providers only is on next page.
If case light still do not come on, it may need to be replaced.
• Contact Structural Concepts' Technical Service Department for replacement light
(see TECHNICAL SERVICE section of this manual for contact information).
•
To replace, disconnect plug from existing LED light. Disconnect LED light from its
brackets. Replace with new LED light. Insert plug ALL THE WAY into LED light orifice.
LED Light
No Gap
TROUBLESHOOTING
Plug
Gap
