CASE DESIGN, CONT'D: REAR VIEW OF SLIDE-IN, SELF-SERVICE UNITS
2. Rear View Of Slide-In, Self-Service Units
• Slide-in unit with rear sliding doors is illustrated below.
• Certain models may have rear panels.
• Handles (at both ends of case) are for pushing/pulling into
position.
• See previous page for front view of merchandiser.
End Glass
Handles Are For
Pushing or
Pulling Unit Into
Position.
Rear Sliding (And
Removable) Doors
Electrical
Box
Rear Panel
Rear Toe-Kick
13
Model NE4827DSSV Is Shown. It May
Not Exactly Reflect Every Feature or
Option Of Your Particular Case.
Field Access
Power Cord
Box
And Plug
Glass
Shelving
Magnets For
Rear Panel
(Typ.)
Magnet For
Rear Toe-Kick
(Typ.)
