6.8 Updating the software

6.8.1 Updating the software of the operating unit

ELT Vmax Operating-instructions-minc98en1-01-(2405)
The device includes various software versions for device operation, the basic device
and the detection system. The version numbers are independent of each other.
Import the software updates using a USB memory stick.
NOTICE
Loss of data due to disconnection
Loss of data due to disconnection
► Do not switch off the device and do not remove the USB flash drive while the
software is being updated.
1 Copy the file into the main directory of a FAT32 formatted USB flash drive.
2 Connect the USB flash drive to a USB port on the device.
3 > Update > Update operating unit
ð The active software version of the operating unit is shown at the top of the
window.
If one or more versions of the software are on the USB flash drive the most
recent version is shown on the line below. If this is the same as the version
already installed the background is green, otherwise it is red.
4 In order to load the new software version, press on the button "Update".
ð
After completion there is an automatic restart of the operating unit.
