6 | Operation

6.3.2 Select product

6.3.3 Using the input field in the measurement window

30 / 50
1 Under "Max. Leak Rate", enter the value at which the product is to be reported
as "leaking". The default setting is 1 x 10
2 Optionally, you can activate a setpoint warning.
3 To enter a barcode, use the touchscreen to enter or scan the bar code in the
activated input field.
4 Via "Select Image" load a product image that will be displayed on the screen
during the measurement.
If your image is not stored on the device, expand the image database. After
pressing you can transfer images (JPG, PNG; max. 400 x 400 px) from a
USB flash drive (FAT32 format) to the image database.
5 Save .
1 > Products
ð Existing products are displayed. If you cannot find the desired product, you
can create it, see "Select, modify or create product (measurement settings)
[} 29]". Click the desired product name.
2 Load .
If required, you can set up an input field in the measurement window to enter an
additional information text there. For example, a serial number or batch number.
This text is not only displayed in the measurement window, but also saved during data
recording. The text is assigned to the measurement performed.
-5
mbar l/s.
