6.7.2.1 Transferring analysis data

ELT Vmax Operating-instructions-minc98en1-01-(2405)
ü Operator or Supervisor rights
1 To transfer data from the internal memory, connect a USB flash drive with
FAT32 formatting to any of the USB ports of the device.
2 > Measurements
3 Save .
ð All measurement data are transferred. There is an indication when the export is
completed. The measurement data remain saved on the device.
Measurement data is only saved if you are using a CP7.
If you do not use CP7, make sure you have your own data collection
The CP7 records data in the internal memory for each measurement and in the event
of an error.
You can either send this file to INFICON via email or request an upload link from
support.
How to provide INFICON with this data
1 Connect a FAT32 formatted USB flash drive to the control unit
2 Navigate to the "Diagnosis
3 Press the "Export Service Data" button
ð The progress of the export is displayed in the operating unit and can take
several minutes (< 25 minutes) after a longer period of use.
ð The USB flash drive should now contain the data export. The file name
consists of the parts "ServiceExport" - "Serial number" - "Date and time".
The data export can be several megabytes (MB) in size after a longer period of use.
This is a password protected archive.
→ Service Export" page in the operating unit
