SECTION 11 - TROUBLESHOOTING

Heating System

Symptom
Wrong temperature and the
alarm is on
Wrong temperature on
touchscreen after system
has had time to stabilise
Temperature differs between
chambers
CO

Gas Regulator

2
Symptom
Wrong CO level
2
measured at sample
port
Poor CO gas
2
regulation
CO concentration
2
alarm
CO pressure alarm
2
O Gas Regulator
2
Symptom
Wrong O level
2
measured at sample
port
Cause
The temperature has not
stabilised within 0.5°C of the
setpoint.
The setpoint for temperature
is wrong
System not properly
calibrated
Cause
System not powered on
CO gas regulator is OFF
2
No CO or wrong gas attached to
2
CO gas input
2
Actual gas concentration is
higher or lower than setpoint
Actual gas concentration is
higher or lower than setpoint
Lid(s) are left open
Seals are damaged or missing on
lid(s)
CO gas concentration more than
2
± 1% from setpoint
No/wrong CO gas pressure to
2
system
Cause
System not powered on
O gas regulator is off
2
No N or wrong gas type
2
attached to N gas input
2
Actual gas concentration is higher
or lower than setpoint
Actual gas concentration is higher
or lower than setpoint
Section 11
Action
Ensure all lids are closed and wait for
the temperature to stabilise.
Check the setpoint temperature and
adjust to the required temperature.
Calibrate each chamber using a high
precision thermometer
Action
Check mains and main fuse
Activate CO gas regulator
2
Check gas supply, make sure that 0.5-
1.0 bar of gas pressure is applied
Check CO setpoint and adjust to the
2
required concentration
Recalibrate the gas concentration
Close lid(s)
Check the seals are intact
Allow system to stabilise by closing all
lids
Check CO gas supply; make sure that
2
pressure is kept stable at 0.5-1.0 bar
Action
Check mains and main fuse
Activate O gas regulator
2
Check gas supply; make sure that 0.5-
1.0 bar of N gas is applied
2
Check O setpoint
2
Calibration of the gas concentration is
needed
Troubleshooting
