Guidance and Manufacturer's Declaration – Electromagnetic Immunity
The G210 is intended for use in the electromagnetic environment specified below. The customer
or the user of the G210 should assure that it is used in such an environment.
IEC 61326-1
IMMUNITY
Test
Electrostatic
discharge
+ 4 kV contact
(ESD)
+ 2, 4, 8 kV air
IEC 61000-
4-2
+/- 1.0kV Burst Potential
Electrical fast
- Mains
transient/
burst
+/- 0.5kV Burst Potential
- Signals/Control
IEC 61000-
4-4
Line-Line: 0.5kV
Combination Wave (1.2μS
x 50μS Voltage, 8μS x
Surge
20μS Current)
IEC 61000-
4-5
Line-Earth: 0.5kV & 1.0
kV Combination Wave
(1.2μS x 50μS Voltage,
8μS x 20μS Current)
100% Reduction; 0.5-1
50Hz Period Cycles; 0° &
Voltage
180° Sync Angle
dips, short
interruptions
30% Reduction; 0.5s
and voltage
Duration; 25 50Hz Period
variations on
Cycles; 0° & 180° Sync
power supply
Angle
input lines
IEC 61000-
100% Reduction; 5s
Duration; 250 50Hz
4-11
Period Cycles; 0° Sync
Angle
Compliance level
Test level
+ 2, 4 kV contact
+ 2, 4, 8 kV air
+/- 1.0kV Burst
Potential - Mains
+/- 0.5kV Burst
Potential - Signals/
Control
Line-Line: 0.5kV
Combination Wave
(1.2μS x 50μS Voltage,
8μS x 20μS Current)
Line-Earth: 0.5kV & 1.0
kV Combination Wave
(1.2μS x 50μS Voltage,
8μS x 20μS Current)
100% Reduction; 0.5-1
50Hz Period Cycles; 0°
& 180° Sync Angle
30% Reduction; 0.5s
Duration; 25 50Hz
Period Cycles; 0° &
180° Sync Angle
100% Reduction; 5s
Duration; 250 50Hz
Period Cycles; 0° Sync
Angle
Section 3
Safety Warnings
Electromagnetic
environment - guidance
Floors should be wood,
concrete or ceramic tile.
If floors are covered with
synthetic material, the
relative humidity should
be at least 30%.
