SECTION 6 - G210 INVICELL PLUS WITH SIGNIPHY™ PH MONITORING
SYSTEM
G210 InviCell Plus with SignipHy pH Monitoring System supports external and independent
monitoring of parameters regarding the performance of culture media, CO
temperature and pH measurement.
All external sensors are completely independent of the functions and controls in the
G210 InviCell Plus with SignipHy pH monitoring as they are connected to and powered by
instruments independent of the G210 InviCell Plus with SignipHy pH Monitoring System.
CAUTION: Installations of external sensors must be performed by CooperSurgical
or by persons authorised by CooperSurgical only.
1
6
1
2
3
4

External Sensors, pH / CO

The following external sensors can be used with the G210 InviCell Plus:
• External pH:
• External CO
20
Connection for external CO
Connection for external pH monitoring (SignipHy™)
Data connection for external thermometer and power
Power connection for external thermometer and power
2
SignipHy™ TrakStation® and Trakpod®
: Cylindrical sensors between 11 and 25mm (e.g. Vaisala GMP251)
2
2
3 4
Figure 6-1 G210 InviCell Plus - back view
Component
sensor
2
concentration,
2
