SECTION 8 - BASIC OPERATION

CAUTION: Do not use the incubator if the alarm system of the device has issued a
failure message and the cause of the failure has not been corrected.
It is important that the appropriate Dish Inserts are selected for the culture dishes used
(LifeGlobal, Falcon, Nunc, Vitrolife) to ensure there is direct contact between the dish and the
heated surface.
Dishes which present no opportunity for an air gap between dish and heated surface can be
placed directly on the heated surface with no need for a Dish Insert.
The use of Dish Inserts requires temperature calibration with the Dish Insert in place (see
"Dish Inserts" on page 5).
1. Place the Dish Inserts in the chamber and close the lid.
2. Wait 30 minutes for the Dish Inserts to heat up.
3. Open the chamber lid.
4. Place the culture dishes containing gametes or embryos on the Dish Inserts ensuring
they are placed securely in the correct milled grooves.
5. Close the lid.
6. Enter the patient ID as per "Edit Chamber Information" on page 25.

Touchscreen Menu

All the unit's functions and settings are controlled from the touchscreen.
When the power is connected the main screen will appear on the display.
The touchscreen can be operated with gloves.
Section 8
Basic Operation
Function Menu
Function Details and Settings
Function Controls
