Service Manual Danfoss Icon2™
4
1
Danfoss
5
Circulation pump
1 set Danfoss Manifold
(types FHF or BasicPlus or SSM)
Thermal actuators, 230V / 24V* TWA-A
* Requires TWA conversion module
4
ESM-11 (PT-1000)
5
Thermal actuator 24V TWA-A
AB432956914381en-010101
2
2
M
M
M
M
3
Mains
Power
ESM-11
5
4
(PT-1000)
© Copyright Danfoss Climate Solutions | 2023.01 | 13
