Service Manual Danfoss Icon2™
4
1
Heat pump
1 set Danfoss Manifold
(types FHF or BasicPlus or SSM)
Thermal actuators, 230V / 24V* TWA-A
* Requires TWA conversion module
Dew Point Sensor CF-DS
4
External voltage free contact from
5
heatpump for changeover between
heating and cooling
AB432956914381en-010101
2
2
M
M
M
M
3
Mains
Power
(Volt free)
Heat demand
signal
Dew Point Sensor
© Copyright Danfoss Climate Solutions | 2023.01 | 19
