Danfoss Icon2 Service Manual page 41

Service Manual Danfoss Icon2™
6
4
Heating supply
1
6
Cooling supply
1
6
Heating return
1
6
Cooling return
1
Reference
1 2-way valve RA-C
Thermostat
1 set Danfoss Manifold
2
(types FHF or BasicPlus
or SSM)
3
Thermal actuators, 230V /
24V* TWA-A
* Requires TWA conversion
module
4 Dew Point Sensor CF-DS
5
Thermal actuators, 230V / 24V* TWA-A
* Requires TWA conversion module
6
Thermal actuators, 230V / 24V* TWA-A
* Requires TWA conversion module
AB432956914381en-010101
2
2
M M M M
3
Mains
Power
1 2 3 4 5
6
© Copyright Danfoss Climate Solutions | 2023.01 | 41
App 10
Dew Point Sensor
4
