Danfoss Icon2 Service Manual page 54

Service Manual Danfoss Icon2™
Application 13
Continued
Installer App settings
Function
PWM+ proportional control of actuator outputs
Heat pump optimizer – maintenance of minimum flow
PWR1 switch-on delay of 3 minutes
Heating supply temperature
Cooling supply temperature
Heating safety temperature
Cooling safety temperature
54 | © Copyright Danfoss Climate Solutions | 2023.01
Required accessories
Factory setting 1
Off On 2
3
40.0 °C
4
18.0 °C
50.0 °C
17.0 °C
5
6
7
8
9
10
6-way ball valve ChangeOver6 DN20
Actuator 230V suitable for ChangeOver6 DN20
2-way control valve with flow regulator AB-QM DN20
Thermal actuator TWA-Q 24V NC suitable for AB-QM DN20
Threaded fittings R3/4" suitable for AB-QM DN20
Stainless steel floor heating manifold SSM-F, 2–12 groups
Set of 2 mounting brackets
Set of 2 ball valves 1"
PT1000 temperature sensor ESM-11
Dew point sensor CF-DS
Thermal actuator TWA-A 230V NC suitable for SSM-F manifold
"Circulation pump Wilo Para 15-130/6"
Heat exchanger XB06H-1-26
Wall switch for manual changeover to cooling
003Z3151
003Z3154
003Z8203
082F1602
003Z0233 (x2)
088U0752 to
088U0762
088U0585
088U0822
087B1165
088U0251
088H3112
145H4269
145H3671
External supplier
