Install the Device in a Rack

Install the Device in a Rack
This procedure uses a two-post mounting kit, which accommodates rack posts 3 inches
or 6 inches wide.
The two-post rack mount kit XN-2P-RMKIT-006 is required for models 5320- 48T-8XE,
5320-48P-8XE, 5320-24T-8XE, and 5320-24P-8XE. The two-post rack mount kit XN-2P-
RMKIT-007 is available for models 5320-16P-4XE and 5320-16P-4XE-DC. The 1U two-
post rack mount kit XN-2P-RMKIT-011 is also available for models 5320-16P-4XE and
5320-16P-4XE-DC. The two-post rack mount kit XN-2P-RMKIT-008 is required for
models 5320-24T-24S-4XE-XT and 5320-24T-4X-XT. The two-post rack mount kits can
also be installed in a four-post rack, using just the two front posts or the two back posts.
The rack mount kit contains an instruction sheet, along with the following
components:
•
Mounting ears (2 count)
•
Mounting ear screws (8 count)
Rack mounting ears can support two configurations: flush- and mid-mount.
Take care to load the rack so that it is not top-heavy. Start installing equipment at the
bottom and work up.
To attach a switch to a two-post rack, follow these steps.
1. Attach a mounting bracket to each side of the switch, using the screws provided.
Align each mounting bracket so that the flange (ear) faces the front of the switch to
flush-mount, or faces the rear of the switch to mid-mount.
The following figures illustrate how to attach the mounting ears for two common
mounting options.
62 ExtremeSwitching 5320 Series Hardware Installation Guide
Note
Do not block the air vent on the top of the unit. Leaving a space between
units ensures adequate airflow.
Note
Do not overlap rack mounting ears when using the longer mounting ears.
Leaving a space between units ensures adequate airflow.
Install Your Switch
