Monitor the Switch
Port LEDs in STK Mode
The port LEDs enter the STK display mode after the Mode button is pressed twice,
indicated by the STK LED. STK mode is used to indicate slot presence and slot number
via the first eight port LED, as referenced by the following table:
Color/State
Steady green
Blinking green This slot has a slot number corresponding to the port number of the
Power LED
The power LED can indicate the status of both the internal power supply and a
connected external redundant power supply (RPS), for models that support connecting
an RPS. The power LED first indicates the status of the internal power supply for one
second, displaying either nothing (off), a green dash, or an amber dash. The power LED
then indicates the state of the external RPS for one second, displaying either nothing
(off), two green dots, or two amber dots. The cycle repeats the two second interval
continuously.
Note
PoE is not supported on models 5320-24T-4X-XT and 5320-24T-24S-4XE-XT.
State
Number
1
2
3
4
5
6
External Redundant Power Supply LEDs
Speed
The slot corresponding to the port number of the LED is present.
blinking LED.
Internal PSU
RPS State
State (dash)
(two dots)
On
Off
On
On
On
Fault
Fault
Not present Amber dash/off Internal PSU FAILed, RPS not
Fault or Off
On
Fault or Off
Fault or Off
ExtremeSwitching 5320 Series Hardware Installation Guide
LED Pattern
Notes
Green dash/off
Internal PSU OK, RPS Not
present.
Green dash/
Both PSUs OK.
Green dots
Green dash/
Internal PSU OK, RPS
Amber dots
PRESENT, but failed or
powered down.
present.
Only valid for PoE systems.
Amber dash/
Internal PSU FAILed or
Green dots
powered down, RPS is good.
Amber dash/
Internal PSU FAILed or
Amber dots
powered down, RPS FAILED
or powered down.
Only valid for PoE systems.
Port LEDs in STK Mode
