Technical Specifications
Figure 65: Null-Modem Cable Pinouts
Figure 66
Figure 66: PC-AT Serial Null-modem Cable Pinouts
Table 23
switches.
Table 23: RJ45 Console Port on Switch
Function
RTS (request to send)
DTR (data carrier detect)
TXD (transmit data)
GND (ground)
shows the pinouts for a 9-pin to 9-pin (PC-AT) null-modem serial cable.
shows the pinouts for the RJ45 console port on the ExtremeSwitching
ExtremeSwitching 5320 Series Hardware Installation Guide
Console Connector Pinouts
Pin Number
1
2
3
4
Direction
Out
Out
Out
—
109
