Technical Specifications
Power cord wall plug
Efficiency
950 W AC Power Supply
The 950 W AC power supply is a fixed internal unit for model 5320-48P-8XE.
Voltage input range
Nominal input ratings
Maximum inrush current
Output
Power supply input socket and
cord
Power cord wall plug
Efficiency
DC Power Supply
The DC power supply is a fixed internal unit for model 5320-16P-4XE-DC.
Table 16: Power Specifications
Voltage input range
Nominal input
DC output
150 W Redundant Power Supply
The 150 W redundant power supply can be used with models 5320-24T-4X-XT and
5320-24T-24S-4XE-XT.
Table 17: Power Specifications
AC Input
DC Output
Refer to Power Cord Requirements for AC-Powered
Switches and AC Power Supplies
Minimum efficiency: 87% at maximum power output
115VAC
90-132/180-264 47 to 63Hz
15A max at 90VAC and 7.5A max at 180VAC at Full 950
W load
60A at Max 230VAC / 50Hz at 25C
12V, 14.1A max, 55V, 14.2A max, 950 W
IEC/EN 60320-1/C16 AC input receptacles
Refer to Power Cord Requirements for AC-Powered
Switches and AC Power Supplies
Minimum efficiency: 87% at maximum power output
115VAC
36 - 72V, 9.8 A max
48Vdc
12V/120W, 54V/200W
100 - 240Vac, 50-60 Hz, 1.8A max. per PSU
12Vdc, 12.5A max. total 150 W max.
ExtremeSwitching 5320 Series Hardware Installation Guide
Power Supply Specifications
on page 108
on page 108
