Environmental

Environmental

Environmental Specifications

EN/ETSI 300 019-2-1 v2.1.2 - Class 1.2 Storage
EN/ETSI 300 019-2-2 v2.1.2 - Class 2.3 Transportation
EN/ETSI 300 019-2-3 v2.1.2 - Class 3.1e Operational
EN/ETSI 300 753 (1997-10) - Acoustic Noise
ASTM D3580 Random Vibration Unpackaged 1.5 G

Environmental Compliance

EU RoHS - 2011/65/EU
EU WEEE - 2012/19/EU
EU REACH – Regulation (EC) No 1907/2006 Reporting
China RoHS - SJ/T 11363-2006
Taiwan RoHS - CNS 15663(2013.7)

Environmental Operating Conditions

Temp: 0°C to 50°C (32°F to 122°F); models 5320-24T-4X-XT and 5320-24T-24S-4XE-XT:
0°C to 60°C (32°F to 140°F)
Humidity: 10% to 95% relative humidity, non-condensing
Altitude: 0 to 3,000 meters (9,850 feet)
Operational Shock (half sine) 300 m/s2 (30 G), 11 ms, 3 axes, 6 shocks/axis
Operational Random vibration: 3 to 500 Hz at 1.5 G rms
Accelerations: 3 Hz @ +10dB/Octave PSD, 10 Hz @ 0.006 PSD, 500 Hz @ 0.006 PSD

Packaging and Storage Specifications

Temp: -40°C to 70°C (-40°F to 158°F)
Humidity: 10% to 95% relative humidity, non-condensing
Packaged Shock (half sine): 3 axes, 100 shocks each axis (+/-), 180 m/s2 (18 G)
Packaged Vibration: 5 Hz to 20 Hz @ .01 g2/Hz (PSD), 20 to 500 Hz @-3 dB/Octave
(PSD)
Packaged Random Vibration: 5 Hz to 62 Hz, 5mm/s velocity, 62 Hz to 500 Hz, 2.0
m/s2, 5 sweeps of each axis (15 total), Sweep Rate = 1 Octave/min
Packaged Drop: Height at 42 inches for product <10 kg, 13 drops including 6 surfaces,
3 edges and 4 corners

Standards

North American ITE
UL 60950-1
UL/CuL 62368-1 Listed
