"TiSO-PRODUCTION" LTD
SERVO-DRIVEN TRIPOD TURNSTILE
GALAXY-M
(AUIA.147-10)
,
OPERATION AND INSTALLATION MANUAL
Combined, rev.1.3.1
2024
UKRAINE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GALAXY-M AUIA.147-10 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Tiso GALAXY-M AUIA.147-10 Series

Summary of Contents for Tiso GALAXY-M AUIA.147-10 Series

  • Page 1 "TiSO-PRODUCTION" LTD SERVO-DRIVEN TRIPOD TURNSTILE GALAXY-M (AUIA.147-10) OPERATION AND INSTALLATION MANUAL Combined, rev.1.3.1 2024 UKRAINE...

  • Page 2: Table Of Contents

    Operation Manual 2 CONTENTS INTRODUCTION ..........................3 CUSTOMER WARNINGS ON SAFE OPERATION OF THE TURNSTILE .........4 1. DESCRIPTION AND OPERATION ....................5 1.1 General Information and Purpose....................5 1.2 Specifications ..........................6 1.3 Product components and scope of delivery ..................6 1.4 Design and operation ........................7 1.5 Instrumentation, tools and accessories ..................7 1.6 Description and operation of controller as an integral component of the turnstile ....10 2.

  • Page 3: Introduction

    Operation Manual 3 INTRODUCTION This Operation Manual (hereinafter referred to as OM) covers the servo-operated turnstile (hereinafter referred to as the "turnstile"). The Operation Manual contains information about design, specifications, installation for proper operation and maintenance of the turnstile. This Operation Manual is prepared in compliance with the specification requirements...

  • Page 4: Customer Warnings On Safe Operation Of The Turnstile

    Operation Manual 4 CUSTOMER WARNINGS ON SAFE OPERATION OF THE TURNSTILE These warnings are designed to ensure safety during operation of the turnstile to prevent violation of safety features by improper installation or operation. These warnings are aimed at drawing attention of the customer to safety problems.

  • Page 5: Description And Operation

    Operation Manual 5 1. DESCRIPTION AND OPERATION 1.1 General Information and Purpose. 1.1.1 Turnstile purpose: The turnstile is designed for pedestrian movement control at access points of industrial enterprises, banks, stadiums, administrative facilities etc. due to command signals of access control system (from keypad, proximity card readers) or manually (from manual control panel).

  • Page 6: Specifications

    Operation Manual 6 1.2 Specifications Table 4 - Specifications Parameter name Parameter value Minimum traffic flow capacity in single access mode 25 person/min. Maximum access way width 600 mm Power supply voltage: 100  240 V~ 50/60 Hz - AC mains (primary) - DC power supply (secondary) 12 V Consumed power, no more than...

  • Page 7: Design And Operation

    Operation Manual 7 – carbon steel painted in any colour Turnstile assembly according to RAL (reference designation T3. TYК.КE.X); The turnstile basic modification is made of brushed stainless steel 1.3.3 Turnstile scope of delivery Hub with barrier rods (standard):  Tripod turnstile; Remote Control ...
  • Page 8 Operation Manual 8 1.4.1.3 Inside the turnstile post 1 (See fig.2) under the removable lid 4 the panels are fixed on which power supply unit, controllers, terminal blocks for connection to 230 V network and control panel are installed. Controller controls the turnstile motor analyzing signals coming from speed and position sensors and furthermore it provides motor overload protection.
  • Page 9 Operation Manual 9 1.4.1.3 Inside the turnstile post 1 (See fig.2) under the removable lid 4 the panels are fixed on which power supply unit, controllers, terminal blocks for connection to 230 V network and control panel are installed. Controller controls the turnstile motor analyzing signals coming from speed and position sensors and furthermore it provides motor overload protection.

  • Page 10: Instrumentation, Tools And Accessories

    Operation Manual 10 After the signal is deactivated from the input (in1) or deactivation of the panic mode from control panel, a barrier rod is automatically reset to its initial position. Before turning on the power and turning off the panic, you need to manually check the verticality of the barrier rod (if necessary, lower the leash manually to the stop).
  • Page 11 Operation Manual 11 1.6.1.1 The Controller is assembled on the (85х70)mm card, on which electronic components and connectors for external connections are installed. On controller card 13 LEDs are installed. Their purpose is as follows:  8 LEDs indicate condition of inputs «IN1»  «IN8»; ...
  • Page 12 Operation Manual 12 ХТ1/4 4) voltage on open input ≤ 5 V INP4 ENTRY Not applicable ХТ1/5 INP5 ENTRY To be connected to the ХТ1/6 INP6 ENTRY rotor position sensor ХТ1/7 INP7 ENTRY and motor speed sensor ХТ1/8 INP8 ENTRY ХТ1/9 «-»...
  • Page 13 Operation Manual 13 Programming OPTO XT3.1 XT1.1 RESET OPTO1 Signals from rotor position sensors Signals from Control mechanical unlocking commands from sensors peripherals Control signals Jumpers for of the turnstiles connection of LEDs terminal resistor of RS-485 line XT2.1 Controlled power supply outputs RS-485 XT .1...
  • Page 14 Operation Manual 14 Application of jumpers on the controller board PCB.112.21.20.01: Table 7 - Application of jumpers № State value Description State CONTROLLER PCB 112.21.20.01 Tripod Turnstile type INP 1 INP 2 INP 3 OPTO 1 195 / 196 INP 4 OPTO 2 Mechanism type INP 5...
  • Page 15 Operation Manual 15 1.6.2.3. Description of operation The controller operates according to the program entered into microprocessor memory. The turnstile mechanism and LED displays are controlled according to control commands and status of rotor position sensors based on the logic downloaded into program.
  • Page 16 Operation Manual 16 AUTHORIZATION OF SINGLE ACCESS IN TWO DIRECTIONS Since the turnstile having one rotor can't rotate in two directions simultaneously, the controller can only unlock rotor in two directions and after access in one of directions is started, the reverse direction will be closed. The controller is switched to this mode if in the INITIAL STATUS it simultaneously acquires "TO BE OPENED A"...
  • Page 17 Operation Manual 17 Continued Table 9 OUT3 («DETECTION OF ХТ2/4 EXIT Signal is generated by controller ACCESS А ») 4) resistance of public key when rotor revolves from 64º to OUT4 («DETECTION OF (5÷7) Ohm; ХТ2/5 EXIT 120º in the relevant direction ACCESS B») 5) active level of signal (Factory setting) –...

  • Page 18: Intended Use

    Operation Manual 18 2. INTENDED USE 2.1 Operational limitations 2.1.1 The product should be operated under the conditions specified in 1.1.4 of this document, while keeping the specifications given in section 1.2. FOLLOWING IS PROHIBITED: 1) TO USE THE TURNSTILE NOT FOR APPOINTMENT (see section 1 "DESCRIPTION AND WORK");...
  • Page 19 Operation Manual 19 2.2.2 General layout of the turnstile access ways Option А Option B Fig.11 – Turnstile layout options (conditionally) Fig.12 – Tripod turnstile (single and double) layout (conditionally) 2.2.3 Installation procedure The turnstile installation procedure is as follows: 1) The package integrity to be checked prior to unpacking.
  • Page 20 Operation Manual 20 3) Make sure that the turnstile installation area is ready as follows:  The installation site surface to be flat and horizontal;  Thickness of concrete blinding coat under site to be at least 150 mm. 4)The turnstile fixation holes to be marked on the area surface according to Fig. 13. The turnstile itself can be used as a template, when installed upright on installation site.
  • Page 21 Operation Manual 21 Fig. 14 – Installation of the hub with barrier rods into the tripod turnstile body WARNING:  The turnstile is fixed by means of Redibolt anchors (with jacket and screw) included in the scope of delivery.  The turnstile installation and fixation to be performed only after all electric cables are pulled.
  • Page 22 Operation Manual 22 8) The two rack doors to be removed by turning the lock keys (Fig.15) to access to the "GALAXY-M" tripod turnstile base fixation and service holes. The lid to be removed by turning the lock keys (Fig.16) to access to "GALAXY-M"...
  • Page 23 Operation Manual 23 WARNING:  The turnstile is fixed by means of Redibolt anchors (with jacket and screw) included in the scope of delivery.  The turnstile installation and fixation to be performed only after all electric cables are pulled. The following cables pulled turnstile...
  • Page 24 Operation Manual 24 WARNING: During the turnstile installation it should be taken into account that horizontally positioned barrier rod must be at a distance not more than (50 ÷ 100) mm from access way creator (any surface perpendicular to horizontally positioned barrier rod: enclosure module, wall, etc.). 2.2.4 Adjustment of the locking position of the hub with barrier rods 1.

  • Page 25: Preparation For Use

    Operation Manual 25 Preparation for use 2.3.1 Commission guidelines Prior to the turnstile energization: 1) make sure of proper connection and good condition of all connecting cables; 2) the turnstile barrier rod turning area to be cleaned from foreign particles. When mains cable of power supply unit is connected to network the turnstile control mechanism are energized: barrier rods are locked from rotation in both directions barring access.

  • Page 26: Contingency Actions

    Operation Manual 26 2.4. Contingency actions For emergency evacuation of people (in case of fire, natural disasters, etc.) and to ensure free access, the turnstile to be released by sending the relevant command from control panel. To have fully open passage please use the anti-panic mechanism.

  • Page 27: Current Repair

    Operation Manual 27 - visual inspection of connecting, network and earthing cables condition;- verification of the turnstile performance during manual control in the modes specified in Table 10 or as part of ACS when pendants, identification cards are used;- verification of reliability of the turnstile screw joints and earthing connections - to be tightened, if applicable;- lubrication of all rubbing stop levers, wheel and pinion teeth of the turnstile control mechanism at least monthly with lubricant OKB- 122-7 according to GOST 18179-72 or LITOL 24, Ciatim or engine oil.
  • Page 28 Operation Manual 28 Table 13 Malfunction Cause of malfunction Action Check the power supply switch No AC power supplied to unit The turnstile does not Restore AC power. Loose power cable work when power on. Connect power cable. Faulty power supply unit Replace power supply unit Damaged wires Check wires...

  • Page 29: Checking The Product After Repair

    Operation Manual 29 4.3 Checking the product after repair The turnstile is checked for operability with the help of the remote control after the repair according to Table 10 STORAGE AND TRANSPORTATION 5.1 Do not subject the product to sudden shocks or impacts during storage. You need to use transport trolleys to lift or move the product.

  • Page 30: Annex А.1 Overall And Installation Dimensions Of The "Galaxy-M" Type Turnstile With Stainless Steel Top And Glass Inserts

    Annex А. 1 Overall and installation dimensions of the "GALAXY-M" type turnstile with stainless steel top and glass inserts 1310 1314 147 - 10.05.00.00 Stainlles steel top with glass inserts 1312 1314 A-A ( 1 : 5 ) 1310 1085 Ø...

  • Page 31: Glass Top

    Annex А.2 Overall and installation dimensions of the "GALAXY-M" type turnstile with solid glass top 1310 1320 147 - 10.05.00.00 .01 Solid glass top 1316 1320 A-A ( 1 : 5 ) 1310 1085 Ø 13 Ø 100 4 holes 2 holes Cable inputs...

  • Page 32: Annex B. Control Panel And Connection Diagram

    Annex B. Control panel and connection diagram 1 – control panel body; 5 – "FREE ACCESS" mode control button 2 – "SINGLE ACCESS" control button 6 – "PANIC" mode control button mode control button 3 – front plate; 7 – access direction LED display; 4 –...

  • Page 33: Annex C. Servo-Operated Tripod Turnstile Wiring Diagram

    Annex C. Servo-operated tripod turnstile wiring diagram CONTROL MECHANISM Control panel A UIA195.07.00.00 A UIA195.00.00.00 XP1 PCB +12V CONTROLLER SPEED CONTROLLER PCB 112.21.20.01 PCB 201.01.00.00 ANGLE 1 ANGLE 2 INP 1 PANIC ZERO 3 INP 2 IN 1 GRN 1 OPEN "A"...

  • Page 34: Annex D.1 Wiring Diagram Of The Turnstile Connection To Access Control System (Acs) In Pulse Mode

    Annex D.1 Wiring diagram of the turnstile connection to access control system (ACS) in pulse mode OPTO XT3.1 XT1.1 RESET OPTO1 Relay 1 Relay 2 XT2.1 Door contact 1 XT .1 Door contact 2 М + GB XT5.1 inp1 - "PANIC" inp2 - "TO BE OPENED A"...

  • Page 35: Annex D.2 Wiring Diagram Of The Turnstile Connection To Access Control System (Acs) In Hold Mode

    Annex D.2. Wiring diagram of the turnstile connection to access control system (ACS) in hold mode...

  • Page 36: Annex D.3 Diagram Of The Turnstile Connection To Fire Alarm (Fa)

    Annex D.3. Diagram of the turnstile connection to fire alarm (FA) OPTO XT3.1 XT1.1 RESET OPTO1 XT2.1 XT .1 М + GB XT5.1 inp1 - "PANIC" inp2 - "TO BE OPENED A" in pulse mode. When command is issued entry is activated for 5 sec. inp3 - "TO BE OPENED B"...

  • Page 37: Annex D.4 Wiring Diagram Of The Turnstile Connection To Fire Alarm System (Fas)

    Annex D.4. Wiring diagram of the turnstile connection to fire alarm system (FAS) OPTO XT3.1 XT1.1 RESET OPTO1 XT2.1 XT .1 М + GB XT5.1 OPTO XT3.1 XT1.1 RESET OPTO1 XT2.1 XT .1 М + GB XT5.1 Figure D.4 – Wiring diagram of the turnstile connection to fire alarm system (FAS)

  • Page 38: Annex D.5 Wiring Diagram Of The Turnstile Connection To Control Panel

    Annex D.5. Wiring diagram of the turnstile connection to control panel OPTO XT1.1 XT3.1 RESET OPTO1 XT2.1 XT .1 М + GB XT5.1...
  • Page 39 Manufacturer: LLC TiSO-PRODUCTION 14, Promyslova Street, Kyiv, 02088, Ukraine Phone: +38 (044) 291-21-11 Tel./fax: +38 (044) 291-21-02 E-mail: sales@tiso.global www.tiso.global SERVICE CENTER e-mail: service1@tiso.global Our equipment meets the requirements of European standards: EN ISO 12100:2010, EN ISO 14118:2018, EN 60204-1:2018,...
